WIRE HARNESSES
LAMP SWITCH
COMBINATION TRIM AND OIL LEAD 1
COMBINATION TRIM AND OIL LEAD 2
TRIM METER LEAD
Part No. Length (L) Remarks
688-82520-00 10 cm (4 in) t = Max.15 mm
Part No. Length (L) Remarks
688-82526-00 10 cm (4 in) t = Max.3 mm
Part No. Length (L) Remarks
64D-82553-50 5 m (16.4 ft)
250G, L250G
64D-82553-70 7 m (23 ft)
64D-82553-80 8 m (26.3 ft)
64D-82553-90 9 m (31.2 ft)
t
L
Y
( L )
t
L
Y
( L )
Or
Gy
B
P
B
P
Or
Gy
G
XX
G/R
G/RG
X
X
( L )
(TRIM)
(TACH)
Part No. Length (L) Remarks
68F-82553-50 5 m (16.4 ft)
250G, L250G
68F-82553-70 7 m (23 ft)
68F-82553-80 8 m (26.3 ft)
68F-82553-90 9 m (31.2 ft)
68F-82553-A0 10.5 m (32.8 ft)
Part No. Length (L) Remarks
6R3-82553-30 3 m (9.8 ft)
Premixed models
w/ PTT
(Flat type harness)
6R3-82553-50 5 m (16.4 ft)
6R3-82553-70 7 m (23 ft)
6R3-82553-80 8 m (26.3 ft)
6R3-82553-90 9 m (31.2 ft)
Or
Gy
B
P
B
P
Or
Gy
GG/R
G/RG
( L )
(TRIM)
(TACH)
L/W
W/R
W/RL/W
Gy
P
OrB
P
Gy
BOr
( L )
