Yamaha TX-480 - Manual Tuning

1 Follow steps 1 and 2 on the previous page.
2
3 Tune to a desired station manually.
Note
If you tune to an FM station manually, it is received in
monaural mode automatically to increase the signal quality.
MANUAL TUNING
8
TUNING MODE
AUTO/MAN’L MONO
2
3
“AUTO TUNING” goes off.
Display information
➀
Displays the band and frequency of the received station.
* TX-580RDS only
If an RDS station is received, the frequency is then
replaced by the station name. (However, if the PS data
cannot be received within 5 seconds, “NO PS” flashes,
and then it returns to the frequency display.)
Refer to page 14 for details.
➁
Illuminates when an FM stereo broadcast is received in
stereo.
➂
Indicates the signal level of the received station.
STEREO
0
MHz
40 60
20
l00
1
3
2
STEREO
0 MHz
20
l00
FM
12
3
TX-580RDS
TX-480, TX-480L
TUNING
* Parts in shaded area are ( )
present on TX-580RDS only.
