Operation
28
1. Pour engine oil into the remote oil tank.
NOTE:
The oil level lines on the remote oil tank indi-
cate the amount of additional oil that can be
added to the tank. The top oil level line indi-
cates approximately 1.9 L (0.5 US gal, 0.4
Imp gal) can be added, and the bottom oil
level line indicates approximately 3.8 L (1 US
gal, 0.8 Imp gal) can be added.
2. Turn on the main switch. The Yamaha
oil injection system will automatically
feed oil from the remote oil tank to the
engine oil tank.
3. Operate the engine normally.
CAUTION:
ECM00570
When the engine is operated for the first
time or stored for a period of time, a min-
imum of 5 liters (5.3 US qt, 4.4 Imp qt) of
oil should be kept in the remote oil tank.
Otherwise the oil-feed pump chamber will
not be filled with oil, and no oil will be
supplied.
Remote oil tank capacity:
10.5 L (11.10 US qt) (9.24 Imp.qt)
ZMU01877
