2-7
TIGHTENING TORQUES
TIGHTENING TORQUES
ENGINE
△ - marked portion shall be checked for torque tightening after break-in or before each race.
Charging coil 1 resistance (color) 720–1,080 Ωat 20 °C (68 °F) (Green/
White-Black/Red)
----
Charging coil 2 resistance (color) 44–66
Ωat 20 °C (68 °F) (Black-Green/
Blue)
----
Pickup coil resistance (color) 248–372
Ωat 20 °C (68 °F) (White/Blue-
White/Red)
----
CDI unit-model/manufacturer 1C3-10/YAMAHA ----
Ignition coil:
Model/manufacturer 1C3-00/YAMAHA ----
Minimum spark gap 6 mm (0.24 in) ----
Primary winding resistance 0.24–0.36
Ωat 20 °C (68 °F) ----
Secondary winding resistance 5.7–8.5 k
Ωat 20 °C (68 °F) ----
Spark plug cap:
Resistance 4–6 k
Ωat 20 °C (68 °F) ----
Item Standard Limit
Part to be tightened Thread size Q'ty
Tightening torque
Nm m•kg ft•lb
Spark plug M14S × 1.25 1 20 2.0 14
Cylinder head (nut) M8 × 1.25 5 28 2.8 20
Cylinder head (stud) M8 × 1.25 5 13 1.3 9.4
Cylinder (nut) M8 × 1.25 4 30 3.0 22
Cylinder (stud) M10 × 1.25 4 13 1.3 9.4
Power valve:
Cover M5 × 0.8 4 5 0.5 3.6
Link lever M4 × 0.7 1 4 0.4 2.9
Holder (power valve) M5 × 0.8 4 8 0.8 5.8
Push rod M5 × 0.8 1 5 0.5 3.6
Thrust plate M5 × 0.8 1 4 0.4 2.9
Governor fork M4 × 0.7 2 5 0.5 3.6
Housing M5 × 0.8 3 4 0.4 2.9
Water pump housing cover M6 × 1.0 4 10 1.0 7.2
Coolant drain bolt M6 × 1.0 1 10 1.0 7.2
Radiator M6 × 1.0 6 10 1.0 7.2
Radiator panel M6 × 1.0 2 10 1.0 7.2
Radiator hose clamp M6 × 1.0 8 2 0.2 1.4
Air filter element M6 × 1.0 1 2 0.2 1.4
Carburetor joint M6 × 1.0 4 10 1.0 7.2
Carburetor joint clamp M4 × 0.7 1 2 0.2 1.4
Air filter joint clamp M4 × 0.7 1 2 0.2 1.4
△ Air filter case M6 × 1.0 4 8 0.8 5.8
Air filter guide clamp M5 × 0.8 1 4 0.4 2.9
Reed valve M3 × 0.5 6 1 0.1 0.7
