DESCRIPTION OF PRODUCT
Parts description (Fig. A)
1. Upper handle
2. Switch box
3. Cable clip
4. Grass bag
5. Rear roller
6. Height adjustment lever
7. Carry handle
8. Battery pack tank cover
9. Fixing knob
10. Switch lever
Check the delivery parts (Fig. B)
Remove the machine from its packaging carefully and make sure that all of the following parts
are present:
a. Lawnmower with upper handle
b. Lower brace
c. Grass bag
d. Fixing knob
e. Screws
f. Cable clip
g. Manual
h. Battery pack
i. Charger
WARNING:
If any parts are damaged or missing, do not operate this tool until these
parts have been replaced. Failure to heed this warning could result in serious
personal injury.
NOTE:
Always recycle the packaging in accordance with local recycling guidelines.
INSTALLATION
Assemble the lower handle (Fig. C)
1. Attach the lower brace to the deck.
2. Use two installation screws to x the lower brace.
Attach the top handle to the lawnmower (Fig. D)
Mount the top handle to the lower handle using the two bolts and handle knobs.
Fitting the cable clip (Fig. E)
Ensure that the cable clips supplied are used to x the cable to the lower handle
Assembly of the Grass bag
1. Now assemble the grassbox handle as per g F
2. Lift the lawnmower Safety ap and locate the Grassbox onto the lawnmower support
hooks g G
