12 YASKAWA ELECTRIC TOBP C720600 01E YASKAWA AC Drive Option CDBR-D, LKEB- Installation Manual
◆ Installation Tools
• A Phillips screwdriver (M3.5 to M5 metric / #1, #2, and #3 U.S. standard size).
• A flat-blade screwdriver (blade depth: 0.4 mm (0.02 in.), width: 2.5 mm (0.1 in.)).
Note: This manual does not list tools required to prepare option cables for wiring.
◆ Option Nameplate
■ CDBR Braking Unit
Figure 3
Figure 3 Nameplate Example (CDBR Braking Unit)
■ LKEB Braking Resistor Unit
Figure 4
Figure 4 Nameplate Example (LKEB Braking Resistor Unit)
Model
Input Specifications
Discharge Current
Lot Number
Serial Number
Weight
RoHS
R
Model Revision
Max. Applicable Motor
