PRODUCT CHARACTERISTICS
The plunge router is used to process wood and wood-based materials using shank cutters. The plunge router is equipped with
guides to facilitate straight and angle milling. The possibility of easily connecting the dust extraction system makes work safer. The
correct, reliable, and safe operation of the tool depends on its proper use, therefore:
Read this entire instructions manual before the fi rst use of the tool and keep it for future reference.
The supplier shall not be liable for any damage resulting from failure to comply with the safety instructions and recommendations
specifi ed in this instructions manual.
PRODUCT EQUIPMENT
The tool is delivered complete but requires preparation before beginning operation. The plunge router is supplied with diff erent
attachments allowing various milling methods, guides, dust extraction attachment, and a sleeve for mounting milling cutters with
a smaller handle diameter. Milling cutters are not supplied with the tool.
TECHNICAL DATA
Parameter Unit Value
Catalogue No. YT-82390
Mains voltage [V~] 220 - 240
Mains frequency [Hz] 50
Rated power [W] 710
Rated speed [min
-1
] 13000 - 33000
Milling unit stroke [mm] 20
Insulation class II
Protection rating IPX0
Noise level
- sound pressure L
pA
± K
pA
[dB (A)] 92.0 ± 3.0
- sound power L
wA
± K
wA
[dB (A)] 102.0 ± 3.0
Vibration a
h
± K [m/s
2
] 2.388 ± 1.5
Weight [kg] 3.0
The declared noise emission values have been measured using the standard test method and can be used to compare one tool
to another. The declared noise emission values can also be used for preliminary exposure assessment.
Warning! Noise emissions during the correct operation of a power tool may diff er from the declared values depending on the
manner in which the tool is used, in particular the type of the workpiece.
Warning! Operator protection measures must be determined based on an approximation of exposure under current conditions
of use. All stages of the work cycle must be taken into account. In addition to the working time, other factors must be taken into
account, such as the time when the tool is switched off and when it is idle.
GENERAL WARNINGS FOR THE SAFETY OF POWER TOOLS
Warning! Read all safety warnings, illustrations and specifi cations provided with this power tool. Failure to do so may
result in electric shock, fi re or serious injury.
Keep all warnings and instructions for future reference.
The term “power tool” used in warnings applies to all tools driven by power both wired and wireless.
Workplace safety
Keep the workplace well-lit and clean. Disorder and poor lighting can be causes of accidents.
Do not work with power tools in an environment with an increased risk of explosion, containing fl ammable liquids, gases
or vapors. Power tools generate sparks that can ignite dust or fumes.
Children and third persons should not be allowed to enter the workplace. Loss of concentration can result in loss of control.
Electrical safety
The plug of the electric cable must match the power socket. You must not modify the plug in any way. Do not use any
plug adapters with earthed power tools. An unmodifi ed plug that fi ts the outlet reduces the risk of electric shock.
Avoid contact with earthed surfaces such as pipes, radiators and coolers. Grounding the body increases the risk of electric shock.
