Yealink MeetingBar A10 User Manual

7
Update the rmware of MeetingBar A10 and CTP18 separately.
PC
USB-C Cable
USB-C
Updating the Firmware
10
i
1. (Teams) Go to More > Settings > Device Settings > About to obtain the IP
address.
(Zoom) Go to Settings > General > System Settings > About to obtain the IP
address.
2. Open a web browser and enter the device's IP address in the address bar. For
example, http(s)://10.82.24.11/, and press Enter.
3. Enter the administrator username and the password, and click Login. (The
default user name is "admin", the password is "0000").
4. Go to System > Update.
5. On the right side of Device Firmware, click Select File to upload the desired
rmware.
6. Click Update.
Please get the latest rmware at https://support.yealink.com/.
For other functions and accessories, please refer to the Help Center.
If there are any problems during the deployment, you can submit a ticket at https://ticket.
yealink.com/, and we will have corresponding engineers to deal with it.
Help Center (Teams): Help Center (Zoom):
USB-C
USB-C Cable
9
Wired Content Sharing
Wired Device-USB Mode*
Wired Content Sharing
Video
(Teams)
Wired Content Sharing
Video (Zoom)
*Coming Soon.

Yealink MeetingBar A10 Specifications

General

Bluetooth	Yes
Product type	Video collaboration bar
Product color	Black, Grey
Tracking modes	Presenter mode
Bluetooth version	4.2
Number of cameras	1
Number of persons	- person(s)
Camera type	Single camera
Sensor type	-
Image sensor size	- \
Diagonal field of view	120 °
Horizontal field of view	105 °
Remote control interface	Ethernet
Video codecs	H.264 High profile, H.264 SVC, H.264
Maximum frame rate	30 fps
Maximum video resolution	3840 x 2160 pixels
USB connector type	USB Type-A, USB Type-C
AC input voltage	100 - 240 V
DC output current	0.7 A
DC output voltage	48 V
Power source type	AC
Power consumption (max)	14 W
Power consumption (idle)	10 W
Power consumption (typical)	10.5 W
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Cables included	HDMI, LAN (RJ-45)
HDMI cable length	1.8 m
Networking cable length	3 m
Speaker power	5 W
Operating system installed	Android 10
Mobile operating systems supported	Android 11.0
Microphone sensitivity	88 dB
Number of microphone arrays	8
Security algorithms	256-bit AES, EAP-TLS, MSCHAPv2, PEAP, TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Certification	CE, FCC, RoHS, REACH, ISO 9001, CCC, NOM

Weight and Dimensions

Depth	68 mm
Width	380 mm
Height	82 mm
