Yealink MVC Series User Manual

MVC900 & MVC800 & MVC500 & MVC300 Connection
MVC900 Connection
Do not connect the switch to the Internet, otherwise it will cause network abnormalities.
When starting up the system for the first time, you need a USB hub to connect a mouse to complete the initial configuration.
We recommend using the wireless mouse and keyboard kit.
For more information about the installation and deleployment of accessories (for example, the installation of mini-PC package or
the camera-hub), refer to the Quick Start Guide of corresponding accessory.
5
...
MTouch
MShare
Projector
CAT5e
USB2.0
USB2.0
HDMI
HDMI
HDMI HDMI
Display
Type-B
Ethernet Cable
VCM34(Optional)
VCM34
(Optional)
UVC80
The Back of Mini-PC The Front of Mini-PC
UVC80
CAT5e
CAT5e
CAT5e
CAT5e
CAT5e
CAT5e
CAT5e
Camera-Hub
USB3.0 to Ethernet
Adapter
MSpeaker(Optional)
3m RCA to
3.5mm Audio Cable
Switch
The switch and Ethernet cables should be purchased separately.
VCM34
(Optional)
VCM34
(Optional)
