Yealink RT30 User Manual

3
DECT Repeater RT30 User Guide
Attach the base stand:
1. Align the snap-fits with the corresponding holes and push forward,
snapping them into the holes.
Yealink DECT repeater RT30 is designed in accordance with Digital Enhanced
Cordless Telecommunication (DECT) standard. It can be deployed to extend
the range of the Yealink DECT IP phone (for example, W60P).
If the radio link level of RT30 is excellent to good, each repeater can have up
to two calls (external and internal calls) at any time.
The repeater can be used to extend the range (up to 300m in unobstructed
outdoor areas and up to 50m inside buildings) in a single direction or in all
directions. The automatic handover process is seamless. If the repeater is
placed properly (overlapping the coverage of the base station), the handsets
can move freely within the total coverage while on a call.
Cascade setup:
RT30 supports a sequential or "daisy chain" layout to extend the range in a
single direction. Up to 2 repeaters can be installed in this layout.
Introduction
Multiple Repeaters
50m/300m
W60B
RT30 RT30

Yealink RT30 Specifications

General

RF power	10 mW
LED indicators	Activity, Network, Power
Wall mountable	Yes
Frequency range (EU)	1880 - 1900 MHz
Frequency range (US)	1920 - 1930 MHz
Maximum indoor range	50 m
Maximum outdoor range	300 m
Radio Frequency (RF) range	- MHz
AC input voltage	100 - 240 V
DC output current	0.6 A
DC output voltage	5 V

Weight and Dimensions

Depth	25.1 mm
Width	130 mm
Height	100 mm
Weight	3200 g
