KEY NO. PART NO. Q'TY(PCS) DESCRIPTION
1 4026-01 1 FRONT STABILIZER POST
2 4026-02 1 REAR STABILIZER POST
3 4026-03 2 PIVOT BRACKET
4 4026-04 1 TILT BRACKET
5 4026-05 1 REAR MAIN POST ASSEMBLY
6 4026-06 1 FRONT SUPPORT BRACKET
7 4026-07 1 ANKLE SUPPORT
8 4026-08 1 FOAM ROLLER TUBE
9 4026-09 1 SEAT UPHOLSTERY
10 4026-10 1 BACK UPHOLSTERY
11 4026-11 1 1/2" X 98mm HEX GAN HEAD BOLT
12 4026-12 1 M10 X 85mm HEX HEAD BOLT
13 4026-13 1 M10 X 70mm HEX HEAD BOLT
14 4026-14 1 M10 X 95mm HEX HEAD BOLT
15 4026-15 10 M8 X 20mm HEX HEAD BOLT
16 4026-16 2 BOLT HEAD CAP
17 4026-17 6 10.5mm X 21mm X 1.5mm FLAT WASHER
18 4026-18 2 13.5mm X 26mm X 20mm FLAT WASHER
19 4026-19 3 M10 NYLON LOCKNUT
20 4026-20 1 1/2" NYLON LOCKNUT
21 4026-21 1 O.D. 12.7mm X 84mm PULL PIN
22 4026-22 1 O.D. 10mm X 90mm PULL PIN
23 4026-23 1 O.D. 10mm X 83mm HAND KNOB FIXING PIN
24 4026-24 1 O.D. 10mm X 64mm HEND KNOB FIXING PIN
25 4026-25 1 L SHAPE PULL PIN
26 4026-26 2 FOAM ROLLER TUBE END CAP
27 4026-27 4 STABILIZER END CAP
28 4026-28 2 30mm X 60mm INT. END CAP
29 4026-29 2 38mm SQ. INT. END CAP
30 4026-30 1 50mm SQ. INT. END CAP ( FOR 1.5 t TUBE )
31 4026-31 1 50mm SQ. INT. END CAP ( FOR 3.0 t TUBE )
32 4026-32 1 50mm SQ. EXT. END CAP
33 4026-33 2 FOAM ROLLER
