York 018-060 User Manual

036-21122-002 Rev. B (0103)
14 Unitary Products Group
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
1 Phase
3 Phase
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. HBBA-F036S, HABA-(T,W)036S
INDOOR COIL MODEL NO. G1FA036S17,21
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1150 1250 1350
ID DB (°F) 85 80 70 85 80 70 85 80 70
ID WB (°F) 72 67 57 72 67 57 72 67 57
75
T.C. 38.3 36.1 34.4 37.9 36.3 34.6 38.0 36.4 34.9
S.C. 24.0 23.7 24.0 24.1 24.5 24.7 24.7 25.3 25.2
K.W 3.19 3.14 3.09 3.23 3.20 3.14 3.26 3.23 3.18
85
T.C. 36.9 34.6 32.2 36.9 34.9 32.6 37.0 35.2 33.0
S.C. 24.2 23.7 22.9 24.7 24.6 23.9 25.3 25.5 24.8
K.W 3.45 3.39 3.30 3.50 3.44 3.36 3.53 3.49 3.40
95
T.C. 35.5 33.2 30.0 35.8 33.6 30.4 36.0 34.0 31.0
S.C. 24.3 23.6 21.9 25.4 24.9 23.6 26.0 25.6 24.4
K.W 3.71 3.63 3.52 3.76 3.69 3.58 3.80 3.75 3.62
105
T.C. 33.2 30.4 26.7 33.4 30.8 27.2 33.6 31.3 27.7
S.C. 23.7 22.5 20.7 24.5 23.6 21.9 25.4 24.6 23.0
K.W 3.97 3.84 3.71 4.02 3.91 3.77 4.06 3.96 3.81
115
T.C. 31.0 27.6 23.5 31.1 28.2 24.2 31.3 28.5 24.4
S.C. 23.1 21.3 19.6 23.9 22.6 20.7 24.8 23.7 21.6
K.W 4.22 4.06 3.90 4.29 4.13 3.94 4.33 4.18 4.00
125
T.C. 28.7 24.8 20.2 28.9 25.6 21.1 29.0 25.7 21.0
S.C. 22.5 20.2 18.4 23.2 21.6 19.6 24.2 22.7 20.2
K.W 4.47 4.28 4.09 4.56 4.35 4.11 4.60 4.40 4.19
NOTE: ALL CAPACITIES ARE NET WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM
Air Handler Coil
T.C. S.C. KW
N1AHB1206 G2FD036(S,H)17 1.01 1.00 1.00
N1AHB1206 G2FD046(S,H)17 1.02 1.02 1.00
F2RC/F2FC036 1.00 0.86 1.00
F2RP/F2FP036 1.02 1.01 1.00
F2RP/F2FP042 1.02 1.01 1.01
G1FA036S14 1.00 1.00 1.00
G1FA048S17 1.04 1.04 1.01
G1FA048S21 1.07 1.07 1.04
G1HD036 1.02 1.02 1.05
G2FD046(S,H)17 1.02 1.02 1.00
G1HD048 1.04 1.04 1.05
G1NA036S17J 1.02 1.02 1.01
G1NA036S21C 1.02 1.02 1.00
G1UA036S14 1.00 1.00 1.00
G1UA036S17,21 1.00 1.00 1.00
G1UA048S17 1.04 1.04 1.01
G1UA048S21 1.07 1.07 1.04
G2FD035(S,H)14 0.99 0.99 0.99
G2FD036(S,H)17 1.01 1.00 1.00
G2FD036(S,H)21 1.01 1.00 1.00
G2FD042(S,H)21 1.02 1.02 1.00
Air Handler Coil
T.C. S.C. KW
N1AHB1246 G2FD036(S,H)17 1.00 1.00 0.98
N1AHB1246 G2FD046(S,H)21 1.02 1.02 1.00
F2RC/F2FC036 1.00 0.86 1.00
G1FA048S21 1.07 1.07 1.04
G1NA036S17J 1.02 1.02 1.01
G1NA036S21C 1.02 1.02 1.00
G1UA036S17,21 1.00 1.00 1.00
G1UA048S21 1.07 1.07 1.04
G2FD036(S,H)17 1.01 1.00 1.00
G2FD036(S,H)21 1.01 1.00 1.00
