York 036-048 User Manual

279104-YTG-B-0307
4 Unitary Products Group
- = Not applicable
COOLING CAPACITY - With Air Handler Coils
UNIT MODEL
AIR HANDLER
COIL
1
MODEL
COOLING
MODEL
ELECTRIC
2
HEAT KW
W
RATED
CFM
NET MBH
SEER
W/O TXV
SEER
WITH TXV
3
EER
TOTAL SENS.
3 PH 10 SEER HP WITH MA / MC / N-AH / G2FD
E1RA036S(25,46)
MA12BN2,4 10 17 FC/MC35B3X 1250 34.4 25.3 10 – 8.95
MA12BN2,4 10 17 FC/MC36B3X 1250 34.4 25.3 10 – 8.95
MA12BN2,4 10 17 FC/MC42B3X 1250 34.4 25.3 10 – 8.95
N1AHC1646 10, 15 21 G2FD042(S,H)21 1250 34.2 25.3 10 – 8.95
E2RA048S(25,46
MA16CN4 10, 15 21 FC/MC48C3X 1600 45.5 33.7 10 – 9.45
MA20DN2 10, 15, 25 24 FC/MC48D3X 1725 45.5 33.7 10 – 9.45
MA20DN4 10, 15, 29 24 FC/MC48D3X 1725 45.5 33.7 10 – 9.45
N1AHC1646 10, 15 21 G2FD048(S,H)21 1600 45.5 33.7 10 – 9.45
N1AHD2046 10, 15, 29 24 G2FD048(S,H)24 1600 45.5 33.7 10 – 9.45
E1RA060S(25,46)
MA20DN4 10, 15, 29 24 FC/MC60D3X 2000 57.0 41.0 10 – 9.80
N1AHD2046 10, 15, 29 24 G2FD048(S,H)24 1700 57.0 41.0 10 – 9.80
3 PH 10 SEER HP WITH AHP / SHP / F2RP / RC / FP / FC
4,5
E1RA036S25
F2RP/FP036 5, 8, 10, 15, 19 21 – 1250 34.0 24.9 10 – 9.00
F2RD/FP042 5, 8, 10, 15 21 – 1250 34.0 25.6 10 – 9.00
AHP36C3X 10, 15 21 – 1250 34.0 25.6 10 – 9.00
AHP42C3X 10, 15, 18 21 – 1250 34.0 25.6 10 – 9.00
E2RA048S25
F2FP048 5, 8, 10, 15, 20, 25 24 – 1600 45.0 33.5 10 – 9.40
F2FP060 5, 8, 10, 15, 20, 25 24 – 1600 46.5 34.4 10 – 9.60
AHP/SHP48D3X 10, 15, 18 24 – 1600 46.5 34.4 10 – 9.60
E1RA060S25
F2FP060 5, 8, 10, 15, 20, 25 24 – 1700 56.0 40.0 10 – 9.40
AHP/SHP60D3X 10, 15 24 – 1700 56.0 40.0 10 – 9.40
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ARI Standards 210/240.
Cooling MBH based on 80°F entering air temperature, 50% RH, and rated air flow.
KW includes compressor, outdoor fan and indoor blower motor watts. Add-on coils include 365 watts/1000 CFM for blower motor.
EER (Energy Efficiency Ratio) is the total cooling output in BTU’s at a 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTU’s during a normal annual usage period for cooling divided by the total electric power input
in watt-hours during the same period.
1. G2FD coils available with a factory installed horizontal drain pan. See price pages for specific model number.
2. Single phase units require single phase 2HK heaters.
3. TXV = Use 1TV700 Series Kit.
4. To meet R=4.2 insulation requirements, substitute F2FP for F2RP, and F2FC for F2RC. models. All ratings remain the same.
5. FG8, FG9, and FL8 furnaces and F2RP / F2RC air handlers have B.O.D. standard.
