036-21581-001 Rev. B (0904)
Unitary Products Group 3
NOTE: For high altitude conversion, an orifice change may also be required. See Form 035-14447-001 for application information.
Annual Fuel Utilization Efficiency (AFUE) numbers are determined in accordance with DOE Test procedures.
Wire size and over current protection must comply with the National Electrical Code (NFPA-70-latest edition) and all local codes.
The furnace shall be installed so that the electrical components are protected from water.
* ESP (External Static Pressure) .5" WG is at furnace outlet ahead of cooling coil.
NOTES:
1. All filters must be high velocity cleanable type.
2. Air flows above 1800 CFM require either return from two sides or one side plus bottom.
HIGH ALTITUDE PRESSURE SWITCH APPLICATION
Input (MBH) High Altitude Pressure Switch Kit
Upflow Models 4,500 Ft to 10,000 Ft.
PT9A12N040UP11 1PS0506
PT9B12N060UP11 1PS0501
PT9B12N080UP11 1PS0502
PT9C16N080UP11 1PS0503
PT9C16N100UP11 1PS0503
PT9C20N100UP11 1PS0505
PT9D20N120UP11 1PS0503
ELECTRICAL AND PERFORMANCE DATA
Model
Input
High/Low
Output
High/Low
Nominal
Airflow
AFUE
Air Temp.
Rise
Max. Outlet
Air Temp.
Blower
Blower
Size
Total
Unit
Max.
Over-current
Protect
Min. Wire Size
(awg) @ 75 ft.
One Way
MBH MBH CFM % °F °F HP Amps In. Amps
PT9A12N040UP11 40/26 38/24 1200 94.0 35-65 165 1/2 7.7 10x8 9 20 14
PT9B12N060UP11 60/39 56/36 1200 93.2 40-70 170 1/2 7.7 11x8 9 20 14
PT9B12N080UP11 80/52 75/49 1200 92.5 45-75 175 1/2 7.7 11x8 9 20 14
PT9C16N080UP11 80/52 75/49 1600 92.8 45-75 175 3/4 10.2 11x10 12 20 14
PT9C16N100UP11 100/65 93/61 1600 92.5 45-75 175 3/4 10.2 11x10 12 20 14
PT9C20N100UP11 100/65 93/61 2000 92.8 45-75 175 1 12.7 11x11 14 20 12
PT9D20N120UP11 120/78 112/74 2000 93.2 40-70 170 1 12.7 11x11 14 20 12
FILTER SIZES
Input / Output BTU/H CFM Cabinet Size Side Return Filter in. Bottom Return Filter in.
PT9A12N040UP 1200 A 16 x 25 14 x 25
PT9B12N060UP 1200 B 16 x 25 16 x 25
PT9B12N080UP11 1200 B 16 x 25 16 x 25
PT9C16N080UP11 1600 C 16 x 25 20 x 25
PT9C16N100UP11 1600 C 16 x 25 20 x 25
PT9C20N100UP11 2000 C 16 x 25 20 x 25
PT9D20N120UP11 2000 D (2) 16 x 25 22 x 25
