York AHE18B3XH21 User Manual

6 Johnson Controls Unitary Products
697887-YTG-H-0514
ELECTRIC HEAT PERFORMANCE DATA: 208/230-1-60 & 208/230-3-60
Heater
Models
1,2
Nominal kW
@240V
Total Heat
3
kW Staging
kW MBH W1 Only W1 + W2
208V 230V 208V 230V 208V 230V 208V 230V
1PH
6HK(0,1)6500206 2.4 1.8 2.2 6.2 7.5 1.8 2.2 1.8 2.2
6HK(0,1)6500506 4.8 3.6 4.4 12.3 15.0 3.6 4.4 3.6 4.4
6HK(0,1)6500806 7.7 5.8 7.1 19.7 24.1 5.8 7.1 5.8 7.1
6HK(0,1)6501006 9.6 7.2 8.8 24.6 30.1 7.2 8.8 7.2 8.8
6HK(1,2)6501306 12.5 9.4 11.5 32.0 39.2 3.1 3.8 9.4 11.5
6HK(1,2)6501506 14.4 10.8 13.2 36.9 45.1 3.6 4.4 10.8 13.2
6HK(1,2)6501806 17.3 13.0 15.9 44.3 54.2 6.5 7.9 13.0 15.9
6HK(1,2)6502006 19.2 14.4 17.6 49.2 60.2 7.2 8.8 14.4 17.6
6HK(1,2)6502506 24.0 18.0 22.0 61.5 75.2 7.2 8.8 18.0 22.0
3PH
6HK06501025 9.6 7.2 8.8 24.6 30.1 7.2 8.8 7.2 8.8
6HK06501525 14.4 10.8 13.2 36.9 45.1 10.8 13.2 10.8 13.2
6HK06501825 17.3 13.0 15.9 44.3 54.2 13.0 15.9 13.0 15.9
6HK16502025 19.2 14.4 17.6 49.2 60.2 7.2 8.8 14.4 17.6
6HK16502525 24.0 18.0 22.0 61.5 75.2 9.0 11.0 18.0 22.0
1. (0,1) - 0 = no circuit breaker OR 1 = with circuit breaker.
2. (1,2) - 1 = with circuit breaker, no breaker jumper bar OR 2 = with circuit breaker & breaker jumper bar.
3. For different power distributions, see conversion table on Page 5.
ELECTRICAL DATA FOR SINGLE SOURCE POWER SUPPLY: 208/230-1-60
Air Handler Models
Heater
Models
1,2
Heater
Amps
@240V
Field Wiring
Min. Circuit Ampacity
MOP.
3
Min Wire Size (AWG)
4
208V 230V 208V 230V 208V 230V
AHE18B
6HK(0,1)6500206 10.0 14.3 16.0 15 20 12 12
6HK(0,1)6500506 20.0 25.2 28.5 30 30 10 10
6HK(0,1)6500806 32.0 38.2 43.5 40 45 8 8
6HK(0,1)6501006 40.0 46.8 53.5 50 60 8 6
AHE22B
AHE24B
AHE30B
6HK(0,1)6500206 10.0 14.3 16.0 15 20 12 12
6HK(0,1)6500506 20.0 25.2 28.5 30 30 10 10
6HK(0,1)6500806 32.0 38.2 43.5 40 45 8 8
6HK(0,1)6501006 40.0 46.8 53.5 50 60 8 6
6HK(1,2)6501306 52.0 59.8 68.5 60 70 6 4
6HK(1,2)6501506 60.0 68.5 78.5 70 80 4 4
AHE34C
AHE36C
AHE42D
6HK(0,1)6500206 10.0 16.0 17.6 20 20 12 12
6HK(0,1)6500506 20.0 26.8 30.1 30 35 10 10
6HK(0,1)6500806 32.0 39.8 45.1 40 50 8 8
6HK(0,1)6501006 40.0 48.5 55.1 50 60 8 6
6HK(1,2)6501306 52.0 61.5 70.1 70 80 6 4
6HK(1,2)6501506 60.0 70.1 80.1 80 90 4 4
6HK(1,2)6501806 72.0 83.1 95.1 90 100 4 3
6HK(1,2)6502006 80.0 91.8 105.1 100 110 3 2
AHE48D
6HK(0,1)6500206 10.0 18.3 20.0 20 20 12 12
6HK(0,1)6500506 20.0 29.2 32.5 30 35 10 8
6HK(0,1)6500806 32.0 42.2 47.5 45 50 8 8
6HK(0,1)6501006 40.0 50.8 57.5 60 60 6 6
6HK(1,2)6501306 52.0 63.8 72.5 70 80 6 4
6HK(1,2)6501506 60.0 72.5 82.5 80 90 4 4
6HK(1,2)6501806 72.0 85.5 97.5 90 100 3 3
6HK(1,2)6502006 80.0 94.2 107.5 100 110 3 2
Continuation and notes on next page.
