Johnson Controls Unitary Products 9
697887-YTG-H-0514
LIMITATIONS
These units must be wired and installed in accordance with all
national and local safety codes.
Voltage limits are as follows:
Airflow must be within the minimum and maximum limits
approved for electric heat, evaporator coils and outdoor units.
Air Handler Voltage Voltage code
Normal Operating
Voltage Range
1
1. Rated in accordance with ARI Standard 110, utilization range “A”.
208/230-1-60 06 187-253
AIR FLOW DATA (CFM)
1
Models
Blower
Motor Speed
External Static Pressure (in. wc.)
0.10 0.20 0.30 0.40 0.50 0.60 0.70
AHE18B
High #5 1075 1041 1003 970 930 885 842
Med High #4 895 845 808 767 709 647 561
Med #3 663 618 557 490 348 267 192
Med Low #2 629 468 356 197 175 68 23
Low #1 629 468 356 197 175 68 23
AHE22B
AHE24B
AHE30B
High #5 1156 1120 1093 1056 1014 951 862
Med High #4 1021 987 952 918 873 836 787
Med #3 829 789 754 698 654 585 532
Med Low #2 681 621 575 496 435 336 262
Low #1 598 503 437 340 259 203 74
AHE34C
High #5 1471 1429 1387 1337 1289 1233 1172
Med High #4 1301 1248 1198 1147 1008 999 927
Med #3 1097 1044 972 906 815 748 680
Med Low #2 943 868 768 689 617 566 520
Low #1 869 668 515 424 365 287 NA
AHE36C
High #5 1465 1415 1360 1307 1246 1183 1118
Med High #4 1260 1204 1142 1075 1008 946 876
Med #3 1088 1022 939 862 782 721 626
Med Low #2 998 810 717 630 562 493 444
Low #1 903 707 411 323 265 152 NA
AHE42D
High #5 1632 1589 1542 1494 1446 1391 1335
Med High #4 1430 1390 1346 1294 1238 1168 960
Med #3 1238 1198 1145 1082 993 908 805
Med Low #2 1118 1020 947 851 734 666 563
Low #1 998 772 477 418 349 NA NA
AHE48D
High #5 1861 1823 1787 1750 1708 1666 1620
Med High #4 1674 1640 1599 1562 1516 1472 1432
Med #3 1442 1405 1358 1311 1262 1197 1108
Med Low #2 1257 1220 1163 1103 1031 942 864
Low #1 1153 1031 967 867 764 718 633
AHE60D
High #5 2091 2053 2016 1975 1937 1906 1869
Med High #4 1903 1868 1832 1791 1748 1703 1660
Med #3 1634 1598 1562 1516 1468 1422 1350
Med Low #2 1447 1404 1361 1318 1257 1164 1092
Low #1 1268 1203 1148 1073 978 907 839
1. Air handler units have been tested to UL 1995 / CSA 22.2 standards up to 0.30" wc. external static pressure.
Dry coil conditions only, tested without filters.
For optimal performance, external static pressures of 0.2" to 0.5" are recommended. Applications above 0.6" are not recommended.
Airflow data shown is from testing performed at 230V. AHE units use a X13 motor, and there is minimal variation of airflow at other distribution voltage values. The
above data can be used for airflow at other distribution voltages.
