York AHP18 THRU 60 User Manual

255029-YTG-J-1007
6 Unitary Products Group
PHYSICAL & ELECTRICAL DATA
Models
AHP18B**(N,H)21 AHP24B**(N,H)21 AHP30B**(N,H)21 AHP36C**(N,H)21
Blower - Diameter x Width 9 x 6 10 x 9 10 x 9 10 x 10
Motor
HP 1/3 HP 1/4 HP 1/2 HP 3/4 HP
Nominal RPM 1075 1075 1075 1075
Voltage 230
Amps Full Load (230) 1.9 1.5 2.2 3.6
Filter
1
Type DISPOSABLE OR PERMANENT
Size 16 x 20 x 1 16 x 20 x 1 16 x 20 x 1 20 x 20 x 1
Permanent Type Kit 1PF0601BK 1PF0601BK 1PF0601BK 1PF0602BK
Shipping / Operating Weight (lbs.) - AHP*****N1 128 / 122 132 / 126 139 / 133 162 / 156
Shipping / Operating Weight (lbs.) - AHP*****H1 131 / 125 135 / 129 142 / 136 165 / 159
Models
AHP42C**(N,H)21
AHP48D**(N,H)21
SHP48D**N21
AHP60D**(N,H)21
SHP60D**N21
Blower - Diameter x Width 10 x 10 10 x 10 11 x 10
Motor
HP 3/4 HP 3/4 HP 1 HP
Nominal RPM 1075 1075 1050
Voltage 230
Amps Full Load (230) 3.8 3.8 7.6
Filter
1
Type DISPOSABLE OR PERMANENT
Size 20 x 20 x 1 22 x 20 x 1 22 x 20 x 1
Permanent Type Kit 1PF0602BK 1PF0603BK 1PF0603BK
Shipping / Operating Weight (lbs.) -
AHP*****N1 and SHP*****N21
164 / 158
AHP - 186 / 175
SHP - 182 / 171
AHP - 189 / 178
SHP - 185 / 174
Shipping / Operating Weight (lbs.) - AHP*****H1 167 / 161 190 / 179 193 / 182
1. Field Supplied.
ELECTRICAL DATA - COOLING ONLY (60 Hz)
Models
Total Motor Amps Minimum Circuit Ampacity
Max. O.C.P.
1
Amps/Type
Minimum Wire
Size A.W.G.
60 Hertz 60 Hertz
208V230V208V230V
AHP18B**(N,H)21 1.7 1.9 2.1 2.4 15 14
AHP24B**(N,H)21 1.4 1.5 1.8 1.9 15 14
AHP30B**(N,H)21 2 2.2 2.5 2.8 15 14
AHP36C**(N,H)21 3.3 3.6 4.1 4.5 15 14
AHP42C**(N,H)21 3.4 3.8 4.3 4.8 15 14
AHP48D**(N,H)21 3.4 3.8 4.3 4.8 15 14
SHP48D**N21 3.4 3.8 4.3 4.8 15 14
AHP60D**(N,H)21 7.6 7.6 9.5 9.5 15 14
SHP60D**N21 7.6 7.6 9.5 9.5 15 14
1. OCP = Over Current Protection device, must be HACR type Circuit Breaker or Time Delay fuse.
