York AY012MA321 User Manual

246814-YTG-D-0606
Unitary Products Group 11
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO.
AY012MA321
INDOOR COIL MODEL NO.
G2FD024S17
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM
250 400 550
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65
T.C. 10.5 14.0 13.4 15.1 16.6 13.9 15.6 15.3 17.4 18.9 17.3 17.2 17.2 19.6 21.1
S.C. 10.7 9.7 8.1 8.3 7.0 14.2 12.2 10.5 11.1 8.6 17.6 14.6 12.9 13.9 10.3
KW 1.0 1.1 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0
75
T.C. 10.4 13.6 13.1 14.8 16.5 13.6 15.2 14.9 16.7 18.4 16.8 16.8 16.7 18.7 20.4
S.C. 10.6 9.5 7.9 8.1 7.0 13.8 12.2 10.3 10.7 8.6 17.0 14.8 12.8 13.3 10.2
KW 1.1 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2
85
T.C. 10.3 13.2 12.8 14.5 16.4 13.3 14.8 14.5 16.1 18.0 16.3 16.4 16.1 17.8 19.7
S.C. 10.3 9.2 7.6 7.9 6.9 13.4 12.1 10.2 10.3 8.6 16.5 15.0 12.7 12.7 10.2
KW 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3
95
T.C. 10.2 12.7 12.4 14.1 16.3 13.0 14.3 14.0 15.5 17.6 15.8 16.0 15.6 16.9 18.9
S.C. 10.0 8.9 7.4 7.7 6.9 13.0 12.1 10.0 9.9 8.5 15.9 15.3 12.6 12.1 10.1
KW 1.4 1.4 1.4 1.4 1.4 1.4 1.4 1.4 1.4 1.4 1.4 1.4 1.4 1.4 1.4
105
T.C. 9.9 11.9 11.6 13.4 15.4 12.5 13.5 13.1 14.7 16.6 15.1 15.2 14.7 16.0 17.8
S.C. 9.8 8.5 7.0 7.5 6.5 12.5 11.4 9.5 9.7 8.0 15.3 14.3 12.1 11.9 9.6
KW 1.5 1.5 1.5 1.5 1.6 1.5 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6
115
T.C. 9.6 11.1 10.7 12.7 14.6 12.0 12.7 12.3 13.9 15.7 14.4 14.4 13.8 15.1 16.8
S.C. 9.5 8.1 6.5 7.3 6.1 12.1 10.8 9.0 9.5 7.5 14.6 13.4 11.5 11.7 9.0
KW 1.6 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.8 1.7 1.7 1.8 1.8
125
T.C. 9.3 10.3 9.8 11.9 13.7 11.5 12.0 11.4 13.1 14.7 13.7 13.6 12.9 14.3 15.7
S.C. 9.2 7.8 6.1 7.0 5.7 11.6 10.1 8.6 9.3 7.1 14.0 12.5 11.0 11.5 8.4
KW 1.8 1.8 1.8 1.9 1.9 1.9 1.9 1.9 1.9 1.9 1.9 1.9 1.9 1.9 1.9
NOTE: ALL CAPACITIES ARE NET WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
AHP18 — 1.00 1.00 1.00
— FC/MC/PC18 1.00 1.00 1.00
— G4FA030S14T2A 1.00 1.00 1.00
— G4FA036S17T2A 1.00 1.00 1.00
— G4FA036S21T2A 1.00 1.00 1.00
— G4FD024H14T2A 1.00 1.00 1.00
— G4FD024H17T2A 1.00 1.00 1.00
— G4FD030H17T2A 1.00 1.00 1.00
— G4FD035H14T2A 1.00 1.00 1.00
— HC24 1.00 1.00 1.00
— UC18 1.00 1.00 1.00
Variable Speed
Furnace
Coil T.C. S.C. KW
—————
—————
—————
—————
—————
—————
