10 Unitary Products Group
INDOOR DB
TEMPERATURE,
°F
OUTDOOR TEMPERATURE, °F
-100 102030405060
55 9.7 10.2 10.9 12.1 14.2 17.6 23.3 32.8
70 - - - 3.0 5.1 8.5 14.2 23.7
80 -----4.19.819.3
TABLE 8 - HEATING SUPERHEAT AT COMPRESSOR SUCTION, AIRFLOW = 600 CFM (B1HA018)
OUTDOOR
TEMPERATURE,
°F
INDOOR WB TEMPERATURE, °F
55 57 59 61 63 65 67 69 71 73 75
65 9.2 14.5 19.7 25.0 30.2 35.5 40.8 40.3 39.7 39.2 38.7
70 9.6 14.2 18.8 23.4 28.0 32.5 37.1 37.3 37.5 37.7 37.9
75 10.1 14.0 17.9 21.8 25.7 29.5 33.4 34.3 35.2 36.1 37.0
80 10.5 13.7 17.0 20.2 23.4 26.6 29.8 31.4 33.0 34.6 36.2
85 11.0 13.5 16.0 18.5 21.1 23.6 26.1 28.4 30.7 33.0 35.4
90 11.4 13.3 15.1 16.9 18.8 20.6 22.4 25.5 28.5 31.5 34.5
95 11.9 13.0 14.2 15.3 16.5 17.6 18.8 22.5 26.2 30.0 33.7
100 9.0 10.3 11.7 13.1 14.4 15.8 17.1 20.1 23.0 26.0 28.9
105 6.0 7.6 9.2 10.8 12.4 14.0 15.5 17.7 19.8 22.0 24.1
110 - - 6.7 8.5 10.3 12.1 13.9 15.3 16.6 18.0 19.3
115 - - - 6.3 8.3 10.3 12.3 12.9 13.4 14.0 14.5
TABLE 7 - COOLING SUPERHEAT AT COMPRESSOR SUCTION, AIRFLOW = 600 CFM (B1HA018)
