York D4CE 048 User Manual

OUTDOOR
TEMPERATURE,
°
F
SUPERHEAT AT SCROLL COMPRESSOR SUCTION,
°
F, AIRFLOW = 400 CFM/TON
INDOOR WB TEMPERATURE,
°
F
55 57 59 61 63 65 67 69 71 73 75
65 25.6 26.8 28 29.2 30.4 31.6 32.8 33.3 33.9 34.4 34.9
70 20.1 21.7 23.3 24.9 26.5 28.1 29.6 30.6 31.5 32.4 33.4
75 14.6 16.6 18.5 20.5 22.5 24.5 26.5 27.8 29.1 30.5 31.8
80 9.0 11.4 13.8 16.2 18.5 20.9 23.3 25.0 26.8 28.5 30.3
85 - 6.3 9.0 11.8 14.6 17.4 20.1 22.3 24.4 26.6 28.7
90 - - 6.7 9.1 11.4 13.8 16.2 18.9 21.7 24.4 27.1
95 - - - 6.3 8.3 10.3 12.3 15.6 18.9 22.2 25.6
100 - - - 5.3 6.8 8.4 10.0 13.4 16.8 20.2 23.6
105 ----5.46.57.711.214.718.221.7
110 ------5.49.012.616.219.8
115 -------6.810.514.117.8
TABLE 10
- SUPERHEAT CHARGING TABLE FOR MODEL 036
OUTDOOR
TEMPERATURE,
°
F
SUPERHEAT AT SCROLL COMPRESSOR SUCTION,
°
F, AIRFLOW = 400 CFM/TON
INDOOR WB TEMPERATURE,
°
F
55 57 59 61 63 65 67 69 71 73 75
65 18.1 20.1 22.2 24.3 26.3 28.4 30.5 31.7 32.9 34.2 35.4
70 14.5 16.6 18.7 20.8 22.9 25 27.1 28.7 30.2 31.8 33.4
75 11.0 13.1 15.2 17.4 19.5 21.6 23.7 25.6 27.5 29.5 31.4
80 7.5 9.6 11.7 13.9 16.0 18.2 20.3 22.6 24.8 27.1 29.3
85 - 6.1 8.3 10.4 12.6 14.8 16.9 19.5 22.1 24.7 27.3
90 - - 6.6 8.2 9.8 11.4 13.0 16.1 19.1 22.2 25.2
95 - - - 5.9 7.0 8.0 9.1 12.6 16.1 19.6 23.1
100 - - - 5.3 6.2 7.0 7.9 11.1 14.2 17.4 20.5
105 ----5.46.06.79.512.315.218.0
110 -----5.05.58.010.513.015.4
115 -------6.48.610.712.9
TABLE 11
- SUPERHEAT CHARGING TABLE FOR MODEL 048
OUTDOOR
TEMPERATURE,
°
F
SUPERHEAT AT SCROLL COMPRESSOR SUCTION,
°
F, AIRFLOW = 400 CFM/TON
INDOOR WB TEMPERATURE,
°
F
55 57 59 61 63 65 67 69 71 73 75
65 20.1 22.0 24.0 25.9 27.8 29.8 31.7 32.5 33.3 34.1 35.0
70 16.9 18.9 21.0 23.1 25.2 27.2 29.3 30.3 31.3 32.3 33.4
75 13.7 15.9 18.1 20.3 22.5 24.7 26.9 28.1 29.3 30.5 31.8
80 10.4 12.8 15.1 17.4 19.8 22.1 24.5 25.9 27.3 28.7 30.2
85 7.2 9.7 12.2 14.6 17.1 19.6 22.0 23.7 25.3 27.0 28.6
90 - 6.6 8.9 11.3 13.6 16.0 18.3 20.6 22.8 25.0 27.3
95 - - 5.7 7.9 10.1 12.4 14.6 17.4 20.3 23.1 25.9
100 - - - 6.5 8.2 9.9 11.6 14.6 17.6 20.6 23.6
105 - - - 5.1 6.3 7.4 8.6 11.8 15.0 18.1 21.3
110 ------5.69.012.315.719.0
115 -------6.19.713.216.7
TABLE 12
- SUPERHEAT CHARGING TABLE FOR MODEL 060
530.18-N7Y
12 Unitary Products Group
