York DCMF09NWM42Q1 User Manual

923178-UTG-B-0114
4 Johnson Controls Unitary Products
Outdoor Unit
Model of Outdoor Unit DCMF09CSM42Q1 DCMF12CSM42Q1 DCMF18CSM42Q1 DCMF24CSM42Q1
Compressor Manufacturer/trademark GREE GREE MITSUBISHI SANYO
Compressor Type Inverter Rotary Inverter Rotary Inverter Rotary Inverter Rotary
L.R.A. (A) 16.50 16.50 27 41
Compressor RLA (A) 6.22 6.22 10.86 11.38
Compressor Power Input (W) 950 950 1245 1630
Throttling Method Capillary Capillary Capillary EXV
Working Temp Range (
o
F) 5 ~ 115 5 ~ 115 5 ~ 115 5 ~ 115
Working Temp Range (°C) -15 ~ 46 -15 ~ 46 -15 ~ 46 -15 ~ 46
Condenser Aluminum Fin-copper Tube Aluminum Fin-copper Tube Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter (inch) Φ 0.276 Φ 0.276 Φ 0.276 Φ 0.276
Pipe Diameter (mm) φ7 φ7 φ7 φ7
Rows-Fin Gap (inch) 1 - 0.055 2 - 0.055 2 - 0.055 2 - 0.055
Rows-Fin Gap (mm) 1-1.4 2-1.4 2-1.4 2-1.4
Coil length (L) x height (H) x coil width (L) (inch) 25.5 × 20.8 × 0.8 25.5 × 20.8 × 1.5 33.0 × 26.0 × 1.5 33.6 × 26.0 × 1.5
Coil length (L) x height (H) x coil width (L) (mm) 647 × 19.05 × 528 647 × 38.1 × 528 837 × 38.1 × 660 853 × 38.1 × 660
Fan Motor Speed (rpm) 880±20 880±20 690 690
Output of Fan Motor (W) 21 21 60 60
Fan Motor RLA (A) 0.25 0.25 0.62 0.62
Fan Motor Capacitor (uF) 2 2 3 3.5
Fuse (A) 15A 15A 25A 25A
Air Flow Volume of Outdoor Unit (CFM) 944 944 1887 1887
Air Flow Volume of Outdoor Unit (m
3
/h) 1600 1600 3200 3200
Fan Type-Piece Axial-flow-1 Axial-flow-1 Axial-flow-1 Axial-flow-1
Fan Diameter (inch) 14.6 14.6 20.5 20.5
Fan Diameter (mm) 370 370 520 520
Defrosting Method Automatic Defrosting Automatic Defrosting Automatic Defrosting Automatic Defrosting
Climate Type T1 T1 T1 T1
Permissible Excessive Operating
Pressure for the Discharge Side (PSI)
624 624 624 624
Permissible Excessive Operating
Pressure for the Discharge Side (MPa)
4.3 4.3 4.3 4.3
Permissible Excessive Operating
Pressure for the Suction Side (PSI)
363 363 363 363
Permissible Excessive Operating
Pressure for the Suction Side (MPa)
2.5 2.5 2.5 2.5
Sound Pressure Level dB (A) 49 52 56 56
Sound Power Level dB (A) 59 62 66 66
Dimension (W/D/H) (mm) 28.0 × 12.5 × 21.7 28.0 × 12.5 × 21.7 37.9 × 15.6 × 27.6 37.9 × 15.6 × 27.6
Dimension (W/D/H) (mm) 711 × 318 × 551 711 × 318 × 551 963 × 396 × 701 963 × 396 × 701
Dimension of Package (L/W/H) (inch) 30.4 × 13.7 × 23.3 30.4 × 13.7 × 23.3 40.4 × 17.9 × 28.9 40.4 × 17.9 × 28.9
Dimension of Package (L/W/H) (mm) 771 × 348 × 592 771 × 348 × 592 1026 × 455 × 735 1026 × 455 × 735
Net Weight /Gross Weight (lbs) 64 / 73 68 / 77 104 / 115 112 / 123
Net Weight /Gross Weight (kg) 29 / 33 31 / 35 47 / 52 51 / 56
Refrigerant Charge (oz) 26.1 35.3 44.1 54.7
Refrigerant Charge (kg) 0.74 1.00 1.25 1.55
MCA 10.0 10.0 15.0 16.0
MOP 15.0 15.0 25.0 25.0
Connection Pipe
Length (ft) 25 25 25 25
Length (m) 7.5 7.5 7.5 7.5
Gas additional charge (oz/ft) 0.2 0.2 0.2 0.2
Gas additional charge (g/m) 15 15 15 15
Outer Diameter Liquid Pipe (inch) Φ 1/4 Φ 1/4 Φ 1/4 Φ 1/4
Outer Diameter Liquid Pipe (mm) φ6 φ6 φ6 φ6
Outer Diameter Gas Pipe (inch) Φ 3/8 Φ 3/8 Φ 1/2 Φ 1/2
Outer Diameter Gas Pipe (mm) φ9.52 φ9.52 φ12 φ12
Max Height Distance (ft) 32.8 32.8 32.8 32.8
Max Height Distance (m) 9.9 9.9 9.9 9.9
Max Length Distance (ft) 49.2 49.2 82 82
Max Length Distance (m) 14.9 14.9 24.9 24.9
AIR CONDITIONERS (Continued)
