York DCPM User Manual

923180-UTG-A-1112
4 Johnson Controls Unitary Products
Outdoor Unit
Model of Outdoor Unit DCPM09CSM42Q1 DCPM12CSM42Q1 DCPM18CSM42Q1 DCPM24CSM42Q1 DCPM36CSM42Q1
Compressor Manufacturer/trademark MITSUBISHI MITSUBISHI MITSUBISHI MITSUBISHI MITSUBISHI
Compressor Type Inverter Rotary Inverter Rotary Inverter Rotary Inverter Rotary Inverter Rotary
L.R.A. (A) 10.2 10.2 13.8 18.5 67
Compressor RLA(A) 6.21 5.34 9.35 10.45 13.5
Compressor Power Input(W) 860 860 1200 1420 3010
Throttling Method
Electronic
Expansion Valve
Electronic
Expansion Valve
Electronic
Expansion Valve
Electronic
Expansion Valve
Electronic
Expansion Valve
Working Temp Range (
o
F) 5 ~ 115 5 ~ 115 5 ~ 115 5 ~ 115 5 ~ 115
Working Temp Range (
o
C) -15 ~ 46 -15 ~ 46 -15 ~ 46 -15 ~ 46 -15 ~ 46
Condenser
Aluminum
Fin-copper Tube
Aluminum
Fin-copper Tube
Aluminum
Fin-copper Tube
Aluminum
Fin-copper Tube
Aluminum
Fin-copper Tube
Pipe Diameter (inch) Φ 0.375 Φ 0.375 Φ 0.276 Φ 0.276 φ3/8
Pipe Diameter (mm) φ9.52 φ9.52 φ7 φ7 φ9.52
Rows-Fin Gap (inch) 2 - 0.055 2 - 0.055 2 - 0.055 2 - 0.055 2 - 0.055
Rows-Fin Gap (mm) 2-1.4 2-1.4 2-1.4 2-1.4 2-1.4
Coil length (l) x height (H) x coil width (L) (inch) 29.4 x 20.0 x 1.7 29.4 x 22.0 x 1.7 33.0 x 26.0 x 1.5 38.1 x 29.4 x 1.5 37 × 1.75 × 30
Coil length (l) x height (H) x coil width (L) (mm) 747×44×508 747×44×559 837×38.1×660 967×38.1×748 940.5×44×762
Fan Motor Speed (rpm) 680/900 680/900 800 800 900
Output of Fan Motor (W) 30 30 60 90 170
Fan Motor RLA (A) 0.14 0.14 0.32 1.1 0.45
Fan Motor Capacitor (uF) / / / 4 /
Air Flow Volume of Outdoor Unit (CFM) 944 944 1887 2359 2603
Air Flow Volume of Outdoor Unit (m
3
/h) 1600 1600 3200 4000 4400
Fan Type-Piece Axial-flow Axial-flow Axial-flow Axial-flow Axial-flow
Fan Diameter (inch) 15.7 15.7 20.5 21.7 21.7
Fan Diameter (mm) 400 400 520 552 552
Climate Type T1 T1 T1 T1 T1
Permissible Excessive Operating Pressure for
the Discharge Side (PSI)
624 624 624 624 624
Permissible Excessive Operating Pressure for
the Discharge Side(MPa)
4.3 4.3 4.3 4.3 4.3
Permissible Excessive Operating Pressure for
the Suction Side(PSI)
363 363 363 363 363
Permissible Excessive Operating Pressure for
the Suction Side (MPa)
2.5 2.5 2.5 2.5 2.5
Sound Pressure Level dB (A) 50 52 55 58 65
Sound Power Level dB (A) 60 62 65 68 75
Dimension (W/D/H) (mm) 848 × 540 × 320 848 × 590 × 320 955 × 700 × 396 980 × 790 × 427 980 × 790 × 427
Dimension of Package (W/L/H) (inch) 34.7 x 14.3 x 23.4 34.7 x 14.3 x 25.4 40.5 x 29.1 x 18.5 42.6 x 19.2 x 33.7 42.6 x 19.2 x 33.7
Dimension of Package (W/L/H) ( mm) 881 × 363 × 595 881 × 363 × 645 1029 × 738 × 470 1083 × 488 × 855 1083 × 488 × 855
Net Weight /Gross Weight (lbs) 79.3 / 90.3 88.1 / 96.9 99.1 / 110.1 118.9 / 132.1 161/170
Net Weight /Gross Weight (kg) 36 / 41 40 / 44 45 / 50 54 / 60 73/77
Refrigerant Charge (oz) 45.8 45.8 49.3 56.4 91.7
Refrigerant Charge (kg) 1.30 1.30 1.40 1.60 2.6
MCA 10.0 10.0 16.0 16.0 17.0
MOP 15.0 15.0 20.0 20.0 25.0
Connection Pipe
Length (ft) 24.6 24.6 24.6 24.6 24.6
Length (m) 7.5 7.5 7.5 7.5 7.5
Gas additional charge (oz/ft) 0.2 0.2 0.2 0.2 0.6
Gas additional charge (g/m) 15 15 15 15 50
Outer Diameter Liquid Pipe (inch) Φ 1/4 Φ 1/4 Φ 1/4 Φ 1/4 Φ 1/4
Outer Diameter Liquid Pipe (mm) φ6 φ6 φ6 φ6 φ6
Outer Diameter Gas Pipe (inch) Φ 3/8 Φ 3/8 Φ 1/2 Φ 5/8 Φ 5/8
Outer Diameter Gas Pipe (mm) φ9.52 φ9.52 φ12 φ16 φ16
Max Height Distance (ft) 65 65 65 65 65
Max Height Distance (m) 20 20 20 20 20
Max Length Distance (ft) 100 100 130 130 130
Max Length Distance (m) 30 30 40 40 40
