York DH 180 User Manual

262260-YTG-E-1008
Johnson Controls Unitary Products 13
TABLE 5: DH 210 COOLING CAPACITIES (17.5 TON) (CONTINUED)
AIR ON
EVAPORATOR
COIL
TEMPERATURE OF AIR ON CONDENSER COIL
115°F 125°F
TOTAL
CAP.
1
MBH
POWER
INPUT
2
KW
SENSIBLE CAPACITY, MBH
TOTAL
CAP.
1
MBH
POWER
INPUT
2
KW
SENSIBLE CAPACITY, MBH
ENTERING DRY BULB, °F ENTERING DRY BULB, °F
CFM
WB
°F
90 85 80 75 70 65 90 85 80 75 70 65
5250
77 217.8 12.5 112.3 87.3 62.4 - - - 207.3 10.1 108.4 83.5 58.5 - - -
72 199.9 12.2 143.0 118.0 93.1 68.1 - - 189.9 9.9 138.0 113.1 88.1 63.2 - -
67 182.0 12.0 173.7 148.7 123.8 98.9 73.9 - 172.5 9.7 167.6 142.6 117.7 92.8 67.8 -
62 169.7 11.8 169.7 169.7 146.7 121.7 96.8 71.8 163.2 9.5 163.2 163.2 140.6 115.6 90.7 65.7
57 170.9 11.8 170.9 170.9 146.0 121.1 96.1 71.2 165.4 9.6 165.4 165.4 138.8 113.8 88.9 63.9
6125
77 223.9 16.9 142.1 98.9 69.4 - - - 212.0 16.5 141.0 95.0 65.5 - - -
72 205.5 16.5 162.5 133.0 103.5 74.1 - - 194.2 16.2 157.5 128.0 98.5 69.1 - -
67 187.1 16.1 182.9 167.2 137.7 108.2 78.7 - 176.5 15.8 174.0 161.1 131.6 102.1 72.6 -
62 174.4 15.8 174.4 174.4 163.1 133.6 104.2 74.7 167.0 15.6 167.0 167.0 157.2 127.7 98.2 68.7
57 175.7 15.8 175.7 175.7 162.4 132.9 103.4 74.0 169.2 15.7 169.2 169.2 155.2 125.7 96.2 66.7
7000
77 229.9 21.2 172.0 110.4 76.4 - - - 216.8 23.0 173.6 106.4 72.4 - - -
72 211.0 20.7 182.0 148.0 114.0 80.0 - - 198.6 22.5 177.0 143.0 109.0 74.9 - -
67 192.1 20.2 192.1 185.6 151.6 117.6 83.6 - 180.4 22.0 180.4 179.5 145.5 111.5 77.5 -
62 179.1 19.9 179.1 179.1 179.6 145.6 111.6 77.5 170.8 21.6 170.8 170.8 170.8 139.7 105.7 71.7
57 180.4 19.9 180.4 180.4 178.8 144.8 110.8 76.7 173.1 21.7 173.1 173.1 171.6 137.5 103.5 69.5
7875
72 215.7 20.8 200.1 161.4 122.6 83.9 - - 203.1 22.6 195.0 156.3 117.5 78.8 - -
67 196.4 20.3 196.4 193.2 163.1 124.4 85.6 - 184.5 22.1 184.5 184.1 156.9 118.2 79.4 -
62 183.1 20.0 183.1 183.1 183.4 144.6 105.9 67.1 174.7 21.7 174.7 174.7 174.7 137.4 98.7 59.9
57 184.4 20.0 184.4 184.4 183.6 144.9 106.1 67.4 177.0 21.8 177.0 177.0 176.3 137.5 98.8 60.0
8750
72 220.4 20.9 218.2 174.8 131.3 87.8 - - 207.7 22.7 207.7 169.5 126.1 82.6 - -
67 200.7 20.4 200.7 200.7 174.6 131.1 87.7 - 188.7 22.2 188.7 188.7 168.4 124.9 81.4 -
62 187.1 20.1 187.1 187.1 187.1 143.6 100.2 56.7 178.6 21.8 178.6 178.6 178.6 135.1 91.6 48.1
57 188.5 20.1 188.5 188.5 188.5 145.0 101.5 58.1 181.0 21.9 181.0 181.0 181.0 137.5 94.0 50.5
1. These capacities are gross ratings. For net capacity, deduct the air blower motor, MBH = 3.415 x KW. Refer to the appropriate Blower Performance
Table for the KW of the supply air blower motor.
2. These ratings include the condenser fan motors (Total 1 KW) and the compressor motors but not the supply air blower motor.
Nominal Rating

York DH 180 Specifications

General

Brand	York
Model	DH 180
Category	Air Conditioner
Language	English
