NOTE 1: HACR Type per NEC.
TABLE 22: DH 180, 210 & 240 ELECTRICAL DATA WITH POWERED CONVENIENCE OUTLET
MODEL
(TON-
NAGE)
VOLTAGE
COMPRESSORS
OD FAN
MOTORS
FLA EACH
ID
BLOWER
MOTOR
FLA
CONV
OUTLET
AMPS
HEATER OPTION
MIN.
CIRCUIT
AMPACITY
(AMPS)
MAX.
FUSE/
BRKR
1
SIZE
(AMPS)
RLA
EACH
LRA
EACH
MODEL KW STAGES AMPS
DH180
(15)
208-3-60 21.8 184 4.5 12.8 10.0
None -- -- -- 80.9 100
E18 13.5 1 37.5 80.9 100
E36 27 2 74.9 122.2 125
E54 40.6 2 112.7 169.4 175
E72 54.1 2 150.2 178.7 200
230-3-60 21.8 184 4.3 12.8 10.0
None -- -- -- 80.5 100
E18 18.0 1 43.3 82.6 100
E36 36.0 2 86.6 136.8 150
E54 54.0 2 129.9 158.4 175
E72 72.0 2 173.2 201.7 225
460-3-60 11.0 90 2.2 6.4 5.0
None -- -- -- 40.6 50
E18 18.0 1 21.7 41.3 50
E36 36.0 2 43.3 68.4 70
E54 54.0 2 65.0 79.2 90
E72 72.0 2 86.6 100.9 110
575-3-60 9.6 73 1.7 5.2 4.0
None -- -- -- 34.2 40
E18 18.0 1 17.3 34.2 40
E36 36.0 2 34.6 54.8 60
E54 54.0 2 52.0 63.5 70
E72 72.0 2 69.3 80.8 90
DH210
(17 1/2)
208-3-60 25.6 190 4.5 20.0 10.0
None -- -- -- 96.6 110
E18 13.5 1 37.5 96.6 110
E36 27 2 74.9 131.2 150
E54 40.6 2 112.7 178.4 200
E72 54.1 2 150.2 187.7 200
230-3-60 25.6 190 4.3 20.0 10.0
None -- -- -- 96.2 110
E18 18.0 1 43.3 96.2 110
E36 36.0 2 86.6 145.8 150
E54 54.0 2 129.9 167.4 175
E72 72.0 2 173.2 210.7 225
460-3-60 12.8 95 2.2 10.0 5.0
None -- -- -- 48.2 60
E18 18.0 1 21.7 48.2 60
E36 36.0 2 43.3 72.9 80
E54 54.0 2 65.0 83.7 90
E72 72.0 2 86.6 105.4 110
575-3-60 10.2 75 1.7 7.5 4.0
None -- -- -- 37.9 45
E18 18.0 1 17.3 37.9 45
E36 36.0 2 34.6 57.7 60
E54 54.0 2 52.0 66.3 70
E72 72.0 2 69.3 83.7 90
DH240
(20)
208-3-60 32.1 237 4.5 20.0 10.0
None -- -- -- 111.2 125
E18 13.5 1 37.5 111.2 125
E36 27 2 74.9 131.2 150
E54 40.6 2 112.7 178.4 200
E72 54.1 2 150.2 187.7 200
230-3-60 32.1 237 4.3 20.0 10.0
None -- -- -- 110.8 125
E18 18.0 1 43.3 110.8 125
E36 36.0 2 86.6 145.8 150
E54 54.0 2 129.9 167.4 175
E72 72.0 2 173.2 210.7 225
460-3-60 14.3 130 2.2 10.0 5.0
None -- -- -- 51.6 60
E18 18.0 1 21.7 51.6 60
E36 36.0 2 43.3 72.9 80
E54 54.0 2 65.0 83.7 90
E72 72.0 2 86.6 105.4 110
575-3-60 12.9 85 1.7 7.5 4.0
None -- -- -- 43.9 50
E18 18.0 1 17.3 43.9 50
E36 36.0 2 34.6 57.7 60
E54 54.0 2 52.0 66.3 70
E72 72.0 2 69.3 83.7 90
