343615-YTG-B-0308
Johnson Controls Unitary Products 17
TABLE 18: DY060 COOLING CAPACITIES (5 TON)
Air on Evap-
orator Coil
Temperature of Air on Condenser Coil
75°F 85°F
CFM
WB
(°F)
Total
Cap.
1
(MBH)
Total
2
Input
(kW)
Sensible Capacity (MBH)
1
Return Dry Bulb (°F)
Total
Cap.
1
(MBH)
Total
2
Input
(kW)
Sensible Capacity (MBH)
1
Return Dry Bulb (°F)
86 83 80 77 74 71 68 86 83 80 77 74 71 68
1500
72 73.9 3.7 39.9 35.6 31.3 27.0 22.8 - - 69.2 4.3 38.6 34.3 30.1 25.8 21.5 - -
67 67.1 3.7 50.5 46.3 42.0 37.7 33.4 29.2 24.9 63.1 4.2 48.9 44.6 40.4 36.1 31.8 27.5 23.2
62 60.7 3.6 60.7 55.2 50.9 46.7 42.4 38.1 33.8 57.6 4.1 57.6 53.6 49.4 45.1 40.8 36.5 32.3
57 57.7 3.7 57.7 57.7 54.1 49.8 45.5 41.3 37.0 55.4 4.2 55.4 55.4 51.6 47.4 43.1 38.8 34.5
1750
72 76.2 3.7 44.3 39.2 34.1 29.1 24.0 - - 71.3 4.3 42.9 37.8 32.7 27.7 22.6 - -
67 69.2 3.7 55.9 50.9 45.8 40.8 35.7 30.6 25.6 65.0 4.2 54.1 49.0 44.0 38.9 33.9 28.8 23.8
62 62.7 3.7 62.7 59.9 55.6 50.5 45.4 40.4 35.3 59.4 4.1 59.4 57.4 53.8 48.7 43.7 38.6 33.6
57 59.6 3.7 59.6 59.6 59.0 53.9 48.9 43.8 38.8 57.0 4.2 57.0 57.0 56.3 51.2 46.2 41.1 36.1
2000
72 78.6 3.7 48.7 42.8 37.0 31.2 25.3 - - 73.4 4.3 47.1 41.3 35.4 29.6 23.8 - -
67 71.4 3.7 61.3 55.5 49.6 43.8 38.0 32.1 26.3 66.9 4.2 59.2 53.4 47.6 41.8 35.9 30.1 24.3
62 64.6 3.7 64.6 64.6 60.2 54.3 48.5 42.7 36.9 61.1 4.2 61.1 61.1 58.2 52.4 46.6 40.7 34.9
57 61.4 3.7 61.4 61.4 63.9 58.1 52.2 46.4 40.6 58.7 4.2 58.7 58.7 60.9 55.1 49.2 43.4 37.6
2250
72 79.1 3.7 52.5 45.8 39.2 32.5 25.9 - - 73.8 4.3 50.9 44.2 37.6 30.9 24.3 - -
67 71.9 3.7 66.8 59.2 52.6 45.9 39.3 32.6 26.0 67.3 4.2 63.5 57.1 50.5 43.8 37.2 30.5 23.9
62 65.0 3.7 65.0 65.0 62.8 56.2 49.5 42.9 36.3 61.4 4.2 61.4 61.4 60.0 53.4 46.7 40.1 33.4
57 61.8 3.7 61.8 61.8 63.1 56.4 49.8 43.1 36.5 59.0 4.2 59.0 59.0 60.1 53.5 46.8 40.2 33.6
2500
72 79.6 3.8 56.3 48.8 41.4 33.9 26.5 - - 74.2 4.3 54.6 47.2 39.7 32.3 24.8 - -
67 72.3 3.7 72.3 62.9 55.5 48.0 40.6 33.1 25.7 67.7 4.3 67.7 60.8 53.3 45.9 38.4 31.0 23.5
62 65.5 3.7 65.5 65.5 65.5 58.0 50.6 43.1 35.7 61.8 4.2 61.8 61.8 61.8 54.3 46.9 39.4 32.0
57 62.2 3.7 62.2 62.2 62.2 54.8 47.3 39.9 32.4 59.3 4.2 59.3 59.3 59.3 51.9 44.4 37.0 29.5
95°F 105°F
1500
72 64.6 4.8 37.4 33.1 28.8 24.5 20.2 - - 61.3 5.4 35.6 31.3 27.0 22.8 18.5 - -
67 59.2 4.7 47.3 43.0 38.7 34.4 30.2 25.9 21.6 55.7 5.3 45.6 41.3 37.0 32.7 28.4 24.2 19.9
62 54.6 4.6 54.6 52.1 47.8 43.5 39.3 35.0 30.7 51.5 5.3 51.5 50.0 45.8 41.5 37.2 32.9 28.6
57 53.0 4.7 53.0 53.0 49.2 44.9 40.7 36.4 32.1 50.4 5.3 50.4 50.4 46.5 42.2 38.0 33.7 29.4
1750
72 66.4 4.8 41.5 36.4 31.3 26.3 21.2 - - 62.7 5.4 39.5 34.4 29.4 24.3 19.3 - -
67 60.8 4.7 52.2 47.2 42.1 37.1 32.0 27.0 21.9 57.0 5.3 50.3 45.3 40.2 35.2 30.1 25.1 20.0
62 56.1 4.6 56.1 54.8 52.0 47.0 41.9 36.9 31.8 52.7 5.3 52.7 52.0 49.7 44.7 39.6 34.6 29.5
57 54.5 4.7 54.5 54.5 53.6 48.5 43.4 38.4 33.3 51.6 5.3 51.6 51.6 50.6 45.5 40.5 35.4 30.4
2000
72 68.2 4.8 45.6 39.7 33.9 28.1 22.2 - - 64.1 5.4 43.4 37.6 31.7 25.9 20.1 - -
67 62.5 4.7 57.2 51.4 45.5 39.7 33.9 28.1 22.2 58.3 5.3 55.1 49.3 43.4 37.6 31.8 25.9 20.1
62 57.6 4.7 57.6 57.6 56.3 50.4 44.6 38.8 32.9 53.9 5.3 53.9 53.9 53.7 47.9 42.1 36.2 30.4
57 55.9 4.7 55.9 55.9 57.9 52.1 46.2 40.4 34.6 52.8 5.3 52.8 52.8 54.6 48.8 43.0 37.1 31.3
2250
72 68.5 4.8 49.3 42.6 36.0 29.3 22.7 - - 64.2 5.4 47.1 40.5 33.9 27.2 20.6 - -
67 62.8 4.8 60.1 55.0 48.4 41.7 35.1 28.4 21.8 58.4 5.4 56.8 52.8 46.3 39.7 33.1 26.4 19.8
62 57.8 4.7 57.8 57.8 57.2 50.5 43.9 37.2 30.6 54.0 5.3 54.0 54.0 53.9 47.3 40.6 34.0 27.3
57 56.2 4.7 56.2 56.2 57.2 50.5 43.9 37.2 30.6 52.8 5.3 52.8 52.8 53.8 47.1 40.5 33.9 27.2
2500
72 68.8 4.9 53.0 45.5 38.1 30.6 23.2 - - 64.3 5.5 50.9 43.4 36.0 28.5 21.1 - -
67 63.0 4.8 63.0 58.6 51.2 43.7 36.3 28.8 21.4 58.5 5.4 58.5 56.3 49.2 41.8 34.3 26.9 19.4
62 58.1 4.7 58.1 58.1 58.1 50.6 43.2 35.7 28.3 54.1 5.3 54.1 54.1 54.1 46.6 39.2 31.7 24.3
57 56.4 4.8 56.4 56.4 56.4 49.0 41.5 34.1 26.6 52.9 5.4 52.9 52.9 52.9 45.5 38.0 30.6 23.1
115°F 125°F
1500
72 57.9 6.0 33.8 29.5 25.3 21.0 16.7 - - 54.6 6.7 32.0 27.8 23.5 19.2 14.9 - -
67 52.2 6.0 43.8 39.6 35.3 31.0 26.7 22.5 18.2 48.7 6.6 42.1 37.8 33.6 29.3 25.0 20.7 16.5
62 48.5 5.9 48.5 48.0 43.7 39.4 35.1 30.9 26.6 45.4 6.6 45.4 45.4 41.6 37.3 33.1 28.8 24.5
57 47.8 5.9 47.8 47.8 43.8 39.6 35.3 31.0 26.7 45.2 6.6 45.2 45.2 41.1 36.9 32.6 28.3 24.0
1750
72 59.0 6.0 37.5 32.5 27.4 22.4 17.3 - - 55.3 6.7 35.6 30.5 25.5 20.4 15.4 - -
67 53.1 6.0 48.4 43.4 38.3 33.3 28.2 23.1 18.1 49.3 6.6 46.5 41.5 36.4 31.3 26.3 21.2 16.2
62 49.3 5.9 49.3 49.1 47.4 42.4 37.3 32.3 27.2 46.0 6.5 46.0 46.0 45.1 40.1 35.0 30.0 24.9
57 48.7 5.9 48.7 48.7 47.6 42.5 37.5 32.4 27.4 45.8 6.6 45.8 45.8 44.6 39.6 34.5 29.4 24.4
2000
72 60.0 6.0 41.3 35.4 29.6 23.8 17.9 - - 55.9 6.6 39.1 33.3 27.4 21.6 15.8 - -
67 54.1 5.9 53.0 47.2 41.3 35.5 29.7 23.8 18.0 49.9 6.5 49.9 45.1 39.2 33.4 27.6 21.7 15.9
62 50.2 5.9 50.2 50.2 51.2 45.3 39.5 33.7 27.9 46.5 6.5 46.5 46.5 46.5 42.8 37.0 31.1 25.3
57 49.6 5.9 49.6 49.6 51.4 45.5 39.7 33.9 28.0 46.4 6.5 46.4 46.4 46.4 42.2 36.4 30.6 24.7
2250
72 59.9 6.1 45.0 38.4 31.7 25.1 18.5 - - 55.7 6.7 42.9 36.3 29.6 23.0 16.3 - -
67 54.0 6.0 53.5 50.6 44.3 37.7 31.0 24.4 17.8 49.7 6.6 49.7 48.3 42.3 35.7 29.0 22.4 15.7
62 50.2 5.9 50.2 50.2 50.6 44.0 37.3 30.7 24.1 46.3 6.6 46.3 46.3 46.3 40.7 34.1 27.4 20.8
57 49.5 6.0 49.5 49.5 50.4 43.7 37.1 30.5 23.8 46.1 6.6 46.1 46.1 46.1 40.4 33.7 27.1 20.4
2500
72 59.9 6.1 48.8 41.3 33.9 26.4 19.0 - - 55.4 6.7 46.7 39.2 31.8 24.3 16.9 - -
67 53.9 6.0 53.9 53.9 47.3 39.9 32.4 25.0 17.5 49.4 6.6 49.4 49.4 45.4 37.9 30.5 23.0 15.6
62 50.1 6.0 50.1 50.1 50.1 42.6 35.2 27.7 20.3 46.1 6.6 46.1 46.1 46.1 38.6 31.2 23.7 16.3
57 49.4 6.0 49.4 49.4 49.4 42.0 34.5 27.1 19.6 45.9 6.6 45.9 45.9 45.9 38.5 31.0 23.6 16.1
1. The capacities are gross ratings. For net capacity, deduct indoor blower motor, MBH=3.415 x kW. Refer to the appropriate Blower Perfor-
mance table for the kW of the supply air blower motor.
2. These ratings include the condenser fan motors (total 1 kW) and the compressor motors but not the supply air blower motor.
