York E*BD-(T User Manual

246819-BTG-H-0208
18 Unitary Products Group
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
OUTDOOR UNIT MODEL NO. EABD-F018S
INDOOR COIL MODEL NO. FC/MC/PC/UC18
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 450 600 750
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65
T.C. 16.8 19.2 19.5 21.9 24.5 19.0 20.7 20.8 23.1 25.8 21.2 22.3 22.1 24.3 27.1
S.C. 16.3 14.4 12.7 12.8 10.8 18.4 16.9 14.7 14.6 12.3 20.6 19.5 16.8 16.4 13.8
K.W. 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1
75
T.C. 16.1 18.1 18.3 20.6 23.2 18.1 19.5 19.4 21.8 24.3 20.1 20.9 20.6 23.0 25.4
S.C. 15.6 13.9 12.1 12.3 10.3 17.6 16.3 14.1 14.0 11.7 19.5 18.8 16.0 15.8 13.0
K.W. 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.3
85
T.C. 15.4 17.1 17.0 19.2 21.8 17.2 18.3 18.1 20.4 22.7 19.0 19.6 19.2 21.6 23.6
S.C. 14.9 13.4 11.5 11.7 9.8 16.7 15.7 13.4 13.5 11.0 18.5 18.1 15.3 15.3 12.2
K.W. 1.2 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.4
95
T.C. 14.8 16.0 15.8 17.9 20.4 16.3 17.1 16.8 19.1 21.2 17.9 18.3 17.7 20.3 21.9
S.C. 14.2 12.9 10.9 11.1 9.3 15.8 15.1 12.7 12.9 10.4 17.5 17.4 14.6 14.7 11.4
K.W. 1.3 1.3 1.3 1.4 1.4 1.4 1.4 1.4 1.4 1.4 1.4 1.4 1.4 1.4 1.5
105
T.C. 14.0 14.9 14.7 16.8 19.1 15.4 16.0 15.6 17.8 19.7 16.9 17.0 16.5 18.7 20.4
S.C. 13.5 12.5 10.4 10.7 8.8 15.0 14.5 12.2 12.4 9.9 16.4 16.6 14.0 14.1 10.9
K.W. 1.4 1.4 1.4 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.6
115
T.C. 13.3 13.9 13.7 15.7 17.8 14.5 14.9 14.5 16.4 18.4 15.8 15.8 15.3 17.2 19.0
S.C. 12.8 12.0 9.9 10.2 8.3 14.1 13.9 11.7 11.8 9.4 15.4 15.8 13.4 13.4 10.5
K.W. 1.5 1.5 1.5 1.6 1.6 1.5 1.6 1.5 1.6 1.6 1.6 1.6 1.6 1.6 1.7
125
T.C. 12.5 12.9 12.7 14.6 16.5 13.7 13.7 13.4 15.1 17.0 14.8 14.5 14.1 15.7 17.5
S.C. 12.0 11.6 9.4 9.8 7.8 13.2 13.3 11.1 11.3 8.9 14.4 15.1 12.8 12.8 10.0
K.W. 1.6 1.6 1.6 1.7 1.7 1.6 1.6 1.6 1.7 1.7 1.7 1.7 1.7 1.7 1.8
NOTE: ALL CAPACITIES ARE NET (KBTUH) WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil
T.C. S.C. KW
MA08B FC/MC18B 1.00 1.00 1.00
AHP18 – 1.00 0.92 1.00
F*FP024 – 1.00 0.92 1.00
MV12B FC/MC18B 1.02 1.02 0.98
AV24 – 1.02 1.02 0.98
– HC18 0.99 0.98 0.99
Variable Speed
Furnace
Coil
T.C. S.C. KW
(F,L)L8VA12 FC/MC/PC18A 1.02 1.01 0.97
FL9VA12 FC/MC/PC18A 1.02 1.01 0.97
FL9(C,V)B12 FC/MC/PC18B 1.03 1.02 0.98
(F,L)L8VA12 HC18 1.02 1.01 0.97
FL9VA12 HC18 1.02 1.01 0.97
