036-21300-002-A-0905
Unitary Products Group 5
FIGURE 3 - SUSPENSION MOUNTING (HORIZONTAL) - KEU060, 090 AND 120
+%5
+%5
+%5
+%5
!)2
/54
!)2
).
&(17(5
2)*5$9,7<
.(8
.(8
6833/<$,53/(180$1'
(/(&75,&+($7(5$&&(6625,(6
,167$//('217+,6(1'2)7+(
81,7
:(/'18876
5(7851$,5*5,//+27:$7(5&2,/
$1'67($0&2,/$&&(6625,(6
,167$//('217+,6(1'2)7+(81,7
%
&
$
'
<
;
TABLE 1: UNIT SUSPENSION MOUNTING (HORIZONTAL APPLICATION) WEIGHTS
Unit Model
Shipping
Weight
(lb)
Operating
Weight
(lb)
CG (in) 4-Point Loading (lb)
X Y ABCD
K*EU060 225 210 22.50 15.00 47 51 58 53
K*EU090 340 235 26.50 24.00 78 84 84 78
K*EU120 370 355 26.50 24.00 86 92 92 86
K*EU180 440 425 26.50 24.00 104 77 104 141
TABLE 2: KEU OPERATING WEIGHTS (LBS.)
MODEL 060 090 120 180
BASIC UNIT (Cooling Only) 210 325 325 425
ACCESSORIES
Base 45 55 55 65
Return Air Grill 10151520
Supply Air Plenum 90 100 100 115
Hot Water Coil 70 105 105 135
Steam Coil 80 115 115 145
Electric Heater
10 KW 66
16 KW 70
26 KW 74
36 KW 77
72 KW 125
