York H4DB024 User Manual

036-21024-006 Rev. D (0403)
Unitary Products Group 5
COOLING CAPACITY - With Air Handler Coils
UNIT
MODEL
AIR HANDLER
COIL
1
MODEL
COOLING
MODEL
ELECTRIC
2
HEAT. KW
W
RATED
CFM
NET MBH
SEER
W/O TXV
SEER
+ TXV
3
EER
TOTAL SENS.
1 PH 10 SEER AC WITH N1AH / G2FD
H4DB018 N1AHB0806 2,5,8,10 17 G2FD024(S,H)17 650 18.8 13.9 10.30 - 9.25
H4DB024
N1AHB0806 2,5,8,10 17 G2FD024(S,H)17 810 24.8 18.4 10.50 - 9.75
N1AHB0806 2,5,8,10 17 G2FD030(S,H)17 800 25.0 18.5 10.60 - 10.05
H4DB030
N1AHB1206 5,8,10,15,19 17 G2FD030(S,H)17 1000 29.0 21.5 10.60 - 9.90
N1AHB1206 5,8,10,15,19 17 G2FD036(S,H)17 1000 30.0 22.2 12.20 - 10.85
H4DB036
N1AHB1206 5,8,10,15,19 17 G2FD036(S,H)17 1200 35.6 26.3 10.20 - 9.40
N1AHB1206 5,8,10,15,19 17 G2FD046(S,H)17 1200 36.6 27.1 10.40 - 9.55
H5DB042
N1AHC1606 5,8,10,15,20 21 G2FD042(S,H)21 1400 39.5 29.2 10.00 - 9.00
N1AHC1606 5,8,10,15,20 21 G2FD046(S,H)21 1450 40.0 29.6 10.00 - 9.00
N1AHD2006 8,10,15,20,25,30 24 G2FD048(S,H)24 1450 40.5 30.0 10.40 - 9.30
H5DB048
N1AHC1606 5,8,10,15,20 21 G2FD048(S,H)21 1600 48.5 36.4 10.40 - 10.00
N1AHC1606 5,8,10,15,20 21 G2FD048(S,H)21 1600 48.5 36.4 10.40 - 10.00
N1AHD2006 8,10,15,20,25,30 24 G2FD060(S,H)24 1600 49.0 36.8 10.60 - 10.20
H4DB060 N1AHD2006 8,10,15,20,25,30 24 G2FD060(S,H)24 1950 57.5 42.6 10.00 - 9.55
3 PH 10 SEER AC / N1VS - VARIABLE SPEED
H4DB036
N1VSB12 10,15,18 17 G2FD036(S,H)17 1200 36.0 26.6 10.70 - 9.70
N1VSB12 10,15,18 17 G2FD046(S,H)17 1200 36.6 27.1 11.00 - 10.00
N1VSC16 10,15,18 21 G2FD048(S,H)21 1200 37.6 27.8 11.60 - 10.30
H5DB048 N1VSD20 10,15,18,30 24 G2FD060(S,H)24 1630 49.0 36.8 10.80 - 10.25
H4DB060 N1VSD20 10,15,18,30 24 G2FD061H24 1600 58.0 42.9 10.75 - 9.80
1 PH 10 SEER AC / N1VS - VARIABLE SPEED
H4DB018 N1VSB12 10,15,18 17 G2FD024(S,H)17 650 19.2 14.2 11.35 - 10.25
H4DB024
N1VSB12 10,15,18 17 G2FD024(S,H)17 870 25.6 18.9 11.80 - 11.05
N1VSB12 10,15,18 17 G2FD036(S,H)17 870 26.4 19.5 12.00 - 11.25
H4DB036
N1VSB12 10,15,18 17 G2FD036(S,H)17 1200 36.4 26.9 10.80 - 9.80
N1VSB12 10,15,18 17 G2FD046(S,H)17 1200 37.0 27.4 11.10 - 10.10
N1VSC16 10,15,18 21 G2FD048(S,H)21 1200 38.0 28.1 11.70 - 10.40
H5DB042 N1VSC16 10,15,18 21 G2FD048(S,H)21 1430 41.0 30.3 11.00 - 9.90
H5DB048
N1VSC16 10,15,18 21 G2FD048(S,H)21 1600 49.0 36.8 11.00 - 10.45
N1VSD20 10,15,18,30 24 G2FD048(S,H)24 1600 49.5 37.1 11.05 - 10.65
N1VSD20 10,15,18,30 24 G2FD060(S,H)24 1630 49.0 36.8 10.80 - 10.25
H4DB060
N1VSD20 10,15,18,30 24 G2FD060(S,H)24 1980 59.5 44.0 11.10 - 10.65
N1VSD20 10,15,18,30 24 G2FD061H24 1980 59.5 44.0 11.20 - 10.55
1 PH 10 SEER AC / F2RP / RC / FP / FC
H4DB018
F2RC/FC024 5,8,10 18 - 650 18.5 13.7 10.50 - 9.10
F2RP/FP018 2,5,8 18 - 650 18.0 13.3 10.00 - 9.00
H4DB024
F2RC/FC024 5,8,10 18 - 750 23.0 17.0 10.00 - 9.30
F2RP/FP024 5,8,10 18 - 750 23.8 17.6 10.20 - 9.10
F2RP/FP030 5,8,10,15 18 - 750 24.0 17.8 10.40 - 9.20
F2FP040 5,8,10,15 21 - 810 25.6 18.9 11.25 - 9.85
H4DB030
F2RC/FC030 5,8,10,15 18 - 1000 28.0 20.7 10.40 - 9.60
F2RC/FC036 5,8,10,15 21 - 1000 29.0 21.5 10.50 - 9.70
F2RP/FP030 5,8,10,15 18 - 1000 29.0 21.5 10.55 - 9.80
F2RP/FP036 5,8,10,15,19 21 - 1000 29.8 22.1 10.80 11.00 9.90
For Notes see Page 4.
