York H4TS024 Technical Guide

036-21023-005 Rev. A (0802)
6 Unitary Products Group
Multipliers for determining the performance with other indoor sections.
COOLING PERFORMANCE DATA -
LOW CFM 1-CYLINDER OPERATION
AIR CONDITIONER MODEL NO. H4TS024S06
INDOOR COIL MODEL NO. G2FD036S17+N1VSB12
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 550 600 650
ID DB (°F) 85 80 75 70 85 80 75 70 85 80 75 70
ID WB (°F) 72 67 62 57 72 67 62 57 72 67 62 57
75
T.C. 15.7 14.4 13.1 12.1 15.9 14.5 13.3 12.3 16.0 14.6 13.5 12.4
S.C. 10.4 10.5 10.5 10.1 11.0 10.9 11.1 10.3 11.5 11.4 11.3 10.4
K.W 0.77 0.77 0.77 0.77 0.79 0.77 0.77 0.77 0.80 0.80 0.80 0.80
85
T.C. 14.8 13.7 12.4 11.5 15.1 13.8 12.7 11.7 15.2 13.9 12.8 11.8
S.C. 10.2 10.2 10.2 9.6 10.8 10.7 10.6 9.8 11.2 11.1 10.7 9.9
K.W 0.84 0.84 0.84 0.83 0.86 0.84 0.84 0.83 0.88 1.10 1.09 1.08
95
T.C. 14.1 12.9 11.8 10.9 14.2 13.0 12.0 11.1 14.3 13.2 12.2 11.2
S.C. 10.0 9.9 9.9 9.1 10.5 10.4 10.1 9.3 11.0 11.0 10.2 9.4
K.W 0.92 0.91 0.90 0.89 0.93 0.91 0.90 0.89 0.95 0.94 0.93 0.92
105
T.C. 13.3 12.1 11.2 10.3 13.4 12.2 11.4 10.4 13.4 12.4 11.5 10.6
S.C. 9.8 9.7 9.4 8.6 10.2 10.1 9.5 8.7 10.7 10.4 9.6 8.8
K.W 0.99 0.97 0.96 0.94 1.00 0.97 0.96 0.95 1.02 1.00 0.99 0.98
115
T.C. 12.4 11.3 10.5 9.7 12.5 11.6 10.7 9.8 12.6 11.7 10.8 9.9
S.C. 9.5 9.4 8.8 8.1 9.9 9.7 8.9 8.2 10.4 9.8 9.0 8.3
K.W 1.05 1.03 1.01 1.00 1.06 1.03 1.02 1.00 1.08 1.07 1.05 1.03
125
T.C. 11.5 10.5 9.8 9.1 11.6 11.0 10.0 9.2 11.8 11.0 10.1 9.2
S.C. 9.2 9.1 8.2 7.6 9.6 9.3 8.3 7.7 10.1 9.2 8.4 7.8
K.W 1.10 1.09 1.06 1.06 1.12 1.09 1.08 1.05 1.14 1.14 1.11 1.08
NOTE: ALL CAPACITIES ARE NET WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil
T.C. S.C. KW
N1VSB12 G2FD024S17 0.95 0.96 1.01
N1VSB12 G2FD030S17 0.98 0.98 1.00
G1UA048S17 0.95 1.00 1.04
G1HD036 0.94 0.98 1.07
G2FD030S17 0.94 0.98 1.07
G1FD036S17 0.95 1.00 1.08
G1FA036S17,21 0.92 0.96 1.04
G2FD035S14 0.92 0.96 1.04
G2FD048S21,24 0.95 1.01 0.89
G1FA048S17 0.95 1.00 1.04
G1UA036S17,21 0.92 0.96 1.04
Variable Speed
Furnace
Coil
T.C. S.C. KW
P1XUB12V055 G1UA036S17 0.97 0.98 1.01
P1XUB12V055 G1FA036S17 0.97 0.98 1.01
P1XUB12V055 G2FD024S17 0.95 0.98 1.04
P1XUB12V055 G2FD030S17 0.97 0.98 1.02
P1XUB12V055 G2FD036S17 0.98 0.98 1.02
P1XUB12V055 G2FD046S17 0.98 1.00 1.02
P1DUA12V064 G1UA036S14 0.97 0.98 1.04
P1DUA12V064 G1FA036S14 0.97 0.98 1.04
P1DUA12V064 G1UA030S14 0.95 0.96 1.04
P1DUA12V064 G1FA030S14 0.95 0.96 1.04
