35
YORK INTERNATIONAL
FORM 102.20-RP1(1104)
SHELL COMPONENTS
REF. PART NUMBER DESCRIPTION
1
2 386-11022-001 Corner Connector, Top & Bottom, with shroud
3 021-19750-000 Screw, BH, Hex Socket
4 086-02026-000 Splice Plate, Raceway, No Lifting
5 029-21340-000 Lifting Lug, 6" Baserail
5 029-21365-000 Lifting Lug, 8" & 10" Baserail
6 029-22044-000 Insert, Raceway Bottom, Shipping Split
7 029-22043-000 Insert, Raceway Top, Shipping Split
8 029-22048-000 Insert, Raceway Bottom, Splice
9 029-22039-000 Lifting Lug, Raceway
10 086-02027-001 3" Baserail Splice Angle, Non Lifting
10 086-02027-002 6" Baserail Splice Angle, Non Lifting
10 086-02027-003 8" & 10" Baserail Splice Angle, Non Lifting
11 021-17728-000 Bolt, 1/2"-13
12 021-01163-000 Lockwasher, 1/2"
13 021-02860-000 Nut, 1/2"-13
14 021-08388-000 Bolt, 1/2"-13
15 029-22070-000 Lug, Lifting, Corner, XT, .164 Thk, galv.
16 086-01923-001 Raceway Positioning Angle, No Lifi ting (3" Base Rail or No Base Rail)
17 021-01155-000 Washer, Lock, Int, 3/8
18 021-19305-016 Screw, 3/8"-16
19 021-19307-000 Hex Nut, Lock, 3/8"-16
20 021-01481-000 Bolt, 3/8"-16
21 021-19586-000 Nut, Hex 3/8-16, Zinc Plated
22 029-22047-000 Bracket, Tie Down
23 021-17722-000 Screw, Pan Head, 1/4" x 3/4"
24 028-11778-000 Foam Tape
25 021-19570-000 Bolt, 3/8" x 3/4"
