York LDO9688 User Manual

37
YORK INTERNATIONAL
FORM 102.20-RP1(1104)
SPLICE & SPLIT RACEWAY KITS
KIT PART
NUMBER
DESCRIPTION *
ITEM
PART
NUMBER
DESCRIPTION QTY.
386-17216-001 End Corners Kit
XTI No Baserail
XTI W/ Baserail
XTO W/ Baserail
3 021-19570-000 Screw, Hex Socket Button Head, 3/8 -16 X 3/4,stl Zinc
Pltd,grade 5
32
N/A 021-19568-000 Steel Finishing Plug To Fit 1-1/2” Hole, (Not Shown) 8
2 386-11022-001
Corner Connector, Top & Bottom, with shroud
4
386-17216-002 Split Kit
W/ Lifting XTO
& XTI
9 029-22039-000 Lifting Lug 4
6 029-22044-000 Insert, Raceway Bottom, Shipping Split 4
17 021-01155-000 Wash Lk Th Int 3/8 Std C-76 20
3 021-19570-000 Screw, Hex Socket Button Head, 3/8 -16 X 3/4,stl Zinc
Pltd,grade 5
20
7 029-22043-000 Insert, Raceway 2
386-17216-003 Splice Kit
Top XTO & XTI
N/A 021-01155-000 Wash Lk Th Int 3/8 Std C-76, (Not Shown) 8
3 021-19570-000 Screw, Hex Socket Button Head, 3/8 -16 X 3/4,stl Zinc
Pltd,grade 5
8
7 029-22043-000 Insert, Raceway 2
386-17216-004 Splice Kit
Bottom W/ Lifting
XTO & XTI
9 029-22039-000 Lifting Lug 4
8 029-22048-000 Insert, Raceway Splice 2
17 021-01155-000 Wash Lk Th Int 3/8 Std C-76 12
3 021-19570-000 Screw, Hex Socket Button Head, 3/8 -16 X 3/4,stl Zinc
Pltd,grade 5
12
386-17216-005 End Corners Kit
XTO No Baserail
3 021-19570-000 Screw, Hex Socket Button Head, 3/8 -16 X 3/4,stl Zinc
Pltd,grade 5
32
17 021-19568-000 Steel Finishing Plug To Fit 1-1/2” Hole 8
2 386-11022-001
Corner Connector, Top & Bottom, with shroud
4
15 029-22070-000 Lug,lifting,corner,xt, .164_thk,g90_glv 2
386-17216-006 Split Kit
w/o Lifting XTO
& XTI
6 029-22044-000 Insert, Raceway Bottom, Shipping Split 4
16 086-01923-001 Raceway Positioning Angle 4
17 021-01155-000 Wash Lk Th Int 3/8 Std C-76 20
18 021-19305-016 Screw, Cap Hex 3/8 - 16 Unc - 2a X 1.0, Zinc Plated
Grade 5
20
7 029-22043-000 Insert, Raceway 2
386-17216-007 Splice Kit
Bottom w/o Lifting
XTO & XTI
8 029-22048-000 Insert, Raceway Splice 2
17 021-01155-000 Wash Lk Th Int 3/8 Std C-76 12
3 021-19570-000 Screw, Hex Socket Button Head, 3/8 -16 X 3/4,stl Zinc
Pltd,grade 5
12
4 086-02026-000 Splice Plate - Rcway - No Lifting. 2
* See Shell Components Table
