York MA User Manual

262675-UIM-A-0806
10 Unitary Products Group
* May be 0 (no breaker) or 1 (with breaker).
TABLE 11: Electrical Data - 1 Ø - 208/230-1-60
Models
MA
Heat Kit - Single
Phase
Max.
Static
Min.
Speed
Tap
Total Heat
1
KW Staging
KW MBH W1 Only W2 Only W1 + W2
208V 240V 208V 240V 208V 240V 208V 240V 208V 240V
08BN21
4HK*6500206 0.5 Lo 1.9 2.5 6.4 8.5 1.9 2.5 1.9 2.5 1.9 2.5
4HK*6500506 0.5 Lo 3.6 4.8 12.3 16.4 3.6 4.8 3.6 4.8 3.6 4.8
4HK*6500806 0.5 Med 5.6 7.5 19.2 25.6 2.8 3.75 5.6 7.5 5.6 7.5
4HK*6501006 0.5 Hi 7.2 9.6 24.6 32.8 3.6 4.8 7.2 9.6 7.2 9.6
12BN21
4HK*6500506 0.5 Lo 3.6 4.8 12.3 16.4 3.6 4.8 3.6 4.8 3.6 4.8
4HK*6500806 0.5 Med 5.6 7.5 19.2 25.6 2.8 3.75 5.6 7.5 5.6 7.5
4HK*6501006 0.5 Med 7.2 9.6 24.6 32.8 3.6 4.8 7.2 9.6 7.2 9.6
4HK165N1506 0.5 Med 10.8 14.4 36.9 49.1 3.6 4.8 7.2 9.6 10.8 14.4
14DN21
4HK*6500506 0.5 Lo 3.6 4.8 12.3 16.4 3.6 4.8 3.6 4.8 3.6 4.8
4HK*6500806 0.5 Lo 5.6 7.5 19.2 25.6 2.8 3.75 5.6 7.5 5.6 7.5
4HK*6501006 0.5 Med 7.2 9.6 24.6 32.8 3.6 4.8 7.2 9.6 7.2 9.6
4HK16501506 0.5 Med 10.8 14.4 36.9 49.1 3.6 4.8 7.2 9.6 10.8 14.4
4HK16501806 0.5 Hi 13.2 17.6 45.1 60.1 3.3 4.4 6.6 8.8 13.2 17.6
4HK16502006 0.5 Hi 14.4 19.2 49.2 65.5 3.6 4.8 7.2 9.6 14.4 19.2
16CN21
4HK*6500506 0.5 Lo 3.6 4.8 12.3 16.4 3.6 4.8 3.6 4.8 3.6 4.8
4HK*6500806 0.5 Lo 5.6 7.5 19.2 25.6 2.8 3.75 5.6 7.5 5.6 7.5
4HK*6501006 0.5 Med 7.2 9.6 24.6 32.8 3.6 4.8 7.2 9.6 7.2 9.6
4HK16501506 0.5 Med 10.8 14.4 36.9 49.1 3.6 4.8 7.2 9.6 10.8 14.4
4HK16501806 0.5 Hi 13.2 17.6 45.1 60.1 3.3 4.4 6.6 8.8 13.2 17.6
4HK16502006 0.5 Hi 14.4 19.2 49.2 65.5 3.6 4.8 7.2 9.6 14.4 19.2
20DN21
4HK*6500806 0.5 Lo 5.6 7.5 19.2 25.6 2.8 3.75 5.6 7.5 5.6 7.5
4HK*6501006 0.5 Lo 7.2 9.6 24.6 32.8 3.6 4.8 7.2 9.6 7.2 9.6
4HK16501506 0.5 Med 10.8 14.4 36.9 49.1 3.6 4.8 7.2 9.6 10.8 14.4
4HK16501806 0.5 Med 13.2 17.6 45.1 60.1 3.3 4.4 6.6 8.8 13.2 17.6
4HK16502006 0.5 Med 14.4 19.2 49.2 65.5 3.6 4.8 7.2 9.6 14.4 19.2
4HK16502506 0.5 Med 18.0 24.0 61.5 81.9 3.6 4.8 10.8 14.4 18.0 24.0
1. See conversion Table 10.
TABLE 12: Electrical Data - (For Multi-Source Power Supply) - Copper Wire 1 Ø - 208/230-1-60
Models
MA
Heater
Model
Min. Circuit Ampacity
Max. O.C.P.
1
Amps/Type
1. O.C.P. = Over Current Protection device, must be HACR type Circuit Breaker or Time Delay fuse.
75°C Wire Size - AWG
Circuit Circuit Circuit
1st 2nd 3rd 1st 2nd 3rd 1st 2nd 3rd
208/240 208/240 208/240 208/240 208/240 208/240 208/240 208/240 208/240
12BN21 4HK165N1506 47.5 / 54.4 21.7 / 25.0 – 50 / 60 25 / 25 – 8 / 6 10 / 10 –
14DN21
4HK16501506 46.0 / 53.0 21.7 / 25.0 – 50 / 60 25 / 25 – 8 / 6 10 / 10 –
4HK16501806 42.3 / 48.8 39.7 / 45.8 – 45 / 50 40 / 50 – 8 / 8 8 / 8 –
4HK16502006 46.0 / 53.0 43.3 / 50.0 – 50 / 60 45 / 50 – 8 / 6 8 / 8 –
16CN21
4HK16501506 47.8 / 55.0 21.7 / 25.0 – 50 / 60 25 / 25 – 8 / 6 10 / 10 –
4HK16501806 44.2 / 50.8 39.7 / 45.8 – 50 / 60 40 / 50 – 8 / 6 8 / 8 –
4HK16502006 47.8 / 55.0 43.3 / 50.0 – 50 / 60 45 / 50 – 8 / 6 8 / 8 –
20DN21
4HK16501506 49.3 / 56.5 21.7 / 25.0 – 50 / 60 25 / 25 – 8 / 6 10 / 10 –
4HK16501806 45.7 / 52.3 39.7 / 45.8 – 50 / 60 40 / 50 – 8 / 6 8 / 8 –
4HK16502006 49.3 / 56.5 43.3 / 50.0 – 50 / 60 45 / 50 – 8 / 6 8 / 8 –
4HK16502506 49.3 / 56.5 43.3 / 50.0 21.7 / 25.0 50 / 60 45 / 50 25 / 25 8 / 6 8 / 8 10 / 10
