2 Johnson Controls Unitary Products
5151065-YTG-H-0118
LIST OF SECTIONS
DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
NOMENCLATURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
DIMENSIONS & DUCT CONNECTION DIMENSIONS . . . . . . . . . . . 3
DIMENSIONS - MVC MODULAR AIR HANDLERS
& CM MULTI-POSITION FULL CASED COILS . . . . . . . . . . . . . . . . 3
COOLING CAPACITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
PHYSICAL & ELECTRICAL DATA - COOLING ONLY . . . . . . . . . . 7
kW & MBH CONVERSIONS - FOR TOTAL
POWER INPUT REQUIREMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
APPLICATION FACTORS - RATED CFM VS. ACTUAL CFM . . . . . 7
ELECTRICAL DATA - COOLING ONLY . . . . . . . . . . . . . . . . . . . . . . 7
ELECTRICAL HEAT - MINIMUM FAN SPEED . . . . . . . . . . . . . . . . . 7
ELECTRIC HEAT PERFORMANCE DATA:
208/230-1-60 & 208/230-3-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
ELECTRICAL DATA FOR SINGLE SOURCE
POWER SUPPLY: 208/230-1-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
ELECTRICAL DATA FOR MULTI-SOURCE
POWER SUPPLY: 208/230-1-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
ELECTRICAL DATA FOR SINGLE SOURCE
POWER SUPPLY: 208/230-3-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
ELECTRICAL DATA FOR MULTI-SOURCE
POWER SUPPLY: 208/230-3-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
POWER WIRING - LINE CONNECTIONS . . . . . . . . . . . . . . . . . . . 11
ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
FILTER RACK DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
LIMITATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
TYPICAL APPLICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
COMBUSTIBLE FLOOR BASE ACCESSORY . . . . . . . . . . . . . . . . 12
TYPICAL THERMOSTAT CONNECTION . . . . . . . . . . . . . . . . . . . . 13
AIR FLOW DATA - CFM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
NOMENCLATURE
PRODUCT TYPE
M
M = Modular Blower
POSITION
MOTOR TYPE
V
P = Multi PSC
E = Multi Std ECM
V = Multi VS ECM
OPTIONS
C
C = Communications Ready
- (No Designator) = Standard (No Options)
NOMINAL
AIR FLOW
12
08 = 800 CFM
12 = 1,200 CFM
14 = 1,400 CFM
16 = 1,600 CFM
20 = 2,000 CFM
CABINET WIDTH
B
A = 14.5"
B = 17.5"
C = 21.0"
D = 24.5"
OPTIONS
N
N = No options
VOLTAGE
(Voltage-Phase-Hertz)
2
1 = 115-1-60 3 = 208/230-3-60
2 = 208/230-1-60 4 = 460-3-60
GENERATION
(MAJOR REVISION)
1
1 = 1st Gen
2 = 2nd Gen
etc.
STYLE LETTER
(MINOR REVISION)
NOT USED FOR
ORDERING
A
A = Style A
B = Style B
etc.
