Johnson Controls Unitary Products 7
5151065-YTG-H-0118
PHYSICAL & ELECTRICAL DATA - COOLING ONLY
Models MVC08B MVC12B MVC12C MVC14D MVC16C MVC20D
Blower - Diameter x Width 10 x 8 10 x 8 10 x 8 11 x 10 11 x 10 11 x 10
Motor
HP 1/3 HP 1/2 HP 1/2 HP 1/2 HP 3/4 HP 3/4 HP
Nominal RPM 1050 1050 1050 1050 1050 1050
Voltage 208/230 208/230 208/230 208/230 208/230 208/230
Full Load Amps @230V 2.9 4.5 4.5 4.5 7.0 7.0
Filter
1
Type DISPOSABLE OR PERMANENT
Size 16 x 20 x 1 16 x 20 x 1 20 x 20 x 1 22 x 20 x 1 20 x 20 x 1 22 x 20 x 1
Bottom Rack Kit 1BR01117 1BR01117 1BR01121 1BR01124 1BR01121 1BR01124
Permanent Type Kit
1PF0601 1PF0601 1PF0602 1PF0603 1PF0602 1PF0603
Shipping / Operating Weight (lbs.) 52/51 52/51 68/67 75/74 68/67 75/74
1. Field supplied.
kW & MBH CONVERSIONS - FOR TOTAL POWER INPUT REQUIREMENT
For a power distribution voltage that is different than the provided nominal voltage, multiply the kW and MBH data from the table by
the conversion factor in the following table.
DISTRIBUTION POWER NOMINAL VOLTAGE CONVERSION FACTOR
208V 240V 0.75
220V 240V 0.84
230V 240V 0.92
APPLICATION FACTORS - RATED CFM VS. ACTUAL CFM
% Of Rated Airflow (CFM)
80% 90% 100% 110% 120%
Capacity Factor
0.96 0.98 1.00 1.02 1.03
ELECTRICAL DATA - COOLING ONLY
Models
Motor FLA
1
1. FLA = Full Load Amps.
Minimum Circuit Ampacity
MOP
2
2. MOP = Maximum Overcurrent Protection device; must be HACR type circuit breaker or time delay fuse. Refer to the latest edition of the
National Electric Code or in Canada the Canadian electrical Code and local codes to determine correct wire sizing.
208V 230V 208V 230V
MVC08B
3.0 2.9 3.8 3.6 15
MVC12B/MVC12C/MVC14D
5.0 4.5 6.3 5.6 15
MVC16C/MVC20D
7.3 7.0 9.1 8.8 15
ELECTRICAL HEAT - MINIMUM FAN SPEED
Heater Kit Models
1,2,3
Nom. kW
@240V
Air Handler Models
MVC08B MVC12B MVC12C MVC14D MVC16C MVC20D
6HK(0,1)6500206 2.4kW Med Lo (D) Med Lo (D) Med Lo (D) Med Lo (D) Med Lo (D) Med Lo (D)
6HK(0,1)6500506 4.8kW Med (C) Med Lo (D) Med (C) Med Lo (D) Med Lo (D) Med Lo (D)
6HK(0,1)6500806 7.7kW Med Hi (B) Med Lo (D) Med Hi (B) Med (C) Med Lo (D) Med Lo (D)
6HK(0,1)6501006
6HK36501025
9.6kW Med Hi (B) Med Lo (D) Med Hi (B) Med (C) Med Lo (D) Med Lo (D)
6HK(1,2)6501306 12.5kW Hi (A) Med Hi (B) Med Hi (B) Med (C) Med Lo (D) Med Lo (D)
6HK(1,2)6501506
6HK36501525
14.4kW – Hi (A) Med Hi (B) Med (C) Med Lo (D) Med Lo (D)
6HK(1,2)6501806
6HK36501825
17.3kW – Hi (A) Med Hi (B) Med Hi (B) Med (C) Med (C)
6HK(1,2)6502006
6HK46502025
19.2kW – Hi (A) Hi (A) – Med Hi (B) Med (C)
6HK(1,2)6502506
6HK46502525
24kW – – – – – Med (C)
1. (0,1) - 0 = no service disconnect OR 1 = with service disconnect.
2. (1,2) - 1 = with service disconnect, no breaker jumper bar OR 2 = with service disconnect & breaker jumper bar.
3. 6HK3 = 3-Phase with terminal block connectors only, 6HK4 = 3-Phase with service disconnect.
