505428-YTG-V-0417
30 Johnson Controls Unitary Products
115°F 125°F
3750
77 190.3 18.6 83.0 72.6 55.6 - - - 181.4 20.3 76.6 70.6 53.6 - - -
72 175.7 18.5 115.0 98.0 81.1 64.1 - - 166.8 20.3 112.5 95.6 78.6 61.7 - -
67 161.0 18.4 147.0 123.5 106.5 89.6 72.6 - 152.2 20.3 147.4 120.6 103.6 86.7 69.7 -
62 152.8 18.3 152.8 152.8 128.4 111.4 94.5 77.5 146.2 20.3 146.2 146.2 125.2 108.3 91.3 74.4
4500
77 194.2 18.5 99.6 80.0 60.5 - - - 184.7 20.3 98.1 78.2 58.2 - - -
72 179.2 18.5 127.3 107.7 88.2 68.6 - - 169.9 20.3 125.3 105.4 85.4 65.4 - -
67 164.3 18.4 155.0 135.4 115.9 96.3 76.7 - 155.0 20.3 152.5 132.5 112.6 92.6 72.6 -
62 155.9 18.3 155.9 155.9 139.6 120.1 100.5 80.9 148.9 20.3 148.9 148.9 136.0 116.1 96.1 76.2
57 158.0 18.3 158.0 158.0 138.7 119.1 99.6 80.0 150.8 20.2 150.8 150.8 132.2 112.3 92.3 72.3
5250
77 198.1 18.5 116.2 87.5 65.3 - - - 188.0 20.3 119.7 85.8 62.8 - - -
72 182.8 18.5 139.6 117.4 95.3 73.1 - - 172.9 20.3 138.1 115.1 92.2 69.2 - -
67 167.6 18.4 162.9 147.3 125.2 103.0 80.9 - 157.8 20.3 157.6 144.5 121.5 98.5 75.6 -
62 159.0 18.3 159.0 159.0 150.9 128.7 106.6 84.4 151.5 20.3 151.5 151.5 146.8 123.9 100.9 78.0
57 161.1 18.3 161.1 161.1 149.9 127.7 105.5 83.4 153.5 20.2 153.5 153.5 142.7 119.7 96.8 73.8
6000
77 201.9 18.5 132.8 94.9 70.2 - - - 191.3 20.3 141.2 93.4 67.5 - - -
72 186.4 18.4 151.9 127.1 102.3 77.6 - - 175.9 20.3 150.9 124.9 99.0 73.0 - -
67 170.9 18.4 170.9 159.3 134.5 109.8 85.0 - 160.5 20.3 160.5 156.4 130.4 104.5 78.5 -
62 162.1 18.3 162.1 162.1 162.1 137.4 112.6 87.9 154.2 20.2 154.2 154.2 154.2 131.7 105.7 79.8
57 164.3 18.3 164.3 164.3 161.0 136.3 111.5 86.8 156.2 20.2 156.2 156.2 153.2 127.2 101.3 75.3
6750
72 191.3 18.4 164.9 137.9 110.9 83.8 - - 181.5 20.2 163.8 135.8 107.8 79.7 - -
67 175.4 18.3 175.4 169.6 145.7 118.7 91.7 - 165.6 20.2 165.6 165.4 142.0 114.0 86.0 -
62 166.4 18.2 166.4 166.4 166.4 139.4 112.4 85.3 159.0 20.1 159.0 159.0 159.0 132.7 104.7 76.7
57 168.6 18.2 168.6 168.6 167.0 140.0 113.0 85.9 161.2 20.1 161.2 161.2 159.7 131.6 103.6 75.5
7500
72 196.3 18.3 178.0 148.7 119.4 90.1 - - 187.1 20.0 176.8 146.7 116.6 86.4 - -
67 179.9 18.2 179.9 179.9 156.9 127.6 98.3 - 170.7 20.0 170.7 170.7 153.6 123.5 93.4 -
62 170.7 18.2 170.7 170.7 170.7 141.4 112.1 82.8 163.9 20.0 163.9 163.9 163.9 133.8 103.7 73.5
57 173.0 18.2 173.0 173.0 173.0 143.7 114.4 85.1 166.1 20.0 166.1 166.1 166.1 136.0 105.9 75.7
1
These capacities are gross ratings. For net capacity, deduct supply air blower motor, MBh. Example: Refer to the appropriate Blower
Performance Table for the BHP of the supply air blower motor, MBh = 3.415 x kW and kW = BHP x 0.746
nameplate rated motor
efficiency.
2. These ratings include the condenser fan motors and the compressor motors but not the supply air blower motor.
YD180/ND180/NM180 (Continued)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
