York PAC036 User Manual

036-21346-001 Rev. A (202)
4 Unitary Products Group
FIELD INSTALLED ACCESSORIES
Refer to price manual for specific model numbers:
Start Assist Kit, Time Delay Kit, Electric Heater Kit and Wall
Thermostat.
Electric Heater Kit - Available in 3 different Kw capac-
ities (5, 10, 15 Kw).
Wall Thermostat - The units are designed to operate
with 24-volt electronic and electric-mechanical thermo-
stats.
CONDENSER FAN DATA
MODEL PAC036H1081A PAC048H1081A PAC060H1081A
RPM 1,100 1,100 1,100
HP 1/3 1/3 1/3
Nameplate FLA 1.8 1.8 1.8
Dia. / No. Blades 18 / 3 20 / 4 20 / 4
CFM @ 0 S.P. 2,300 3,000 3,000
EVAPORATOR COIL DATA
MODEL PAC036H1081A PAC048H1081A PAC060H1081A
Face Area (Sq. Ft.) 3.61 4.67 4.67
Tube Dia. Ins. 5/16 5/16 3/8
Rows Deep 3 4 4
Fins / Inch 14 12 12
Orifice .071 .079 .081
EVAPORATOR BLOWER DATA
MODEL PAC036H1081A PAC048H1081A PAC060H1081A
Motor HP -- RPM 3/4 -- 1,000 3/4 -- 1,050 3/4 -- 1,100
Static Pressure
(Inches Water)
.5 .5 .5
Blower Wheel
Dia. x Width
Rated CFM
10 x 7
1,200
10 x 7
1,500
10 x 7
1,600
Nameplate FLA 3.0 3.0 3.0
ELECTRICAL DATA - for Heat Packages Only
HEATER NUMBER 7642-8051 (5.0 KW) 7642-8101 (10.0 KW) 7642-8151 (15.0 KW)
Heater Branch Circuit Electrical Service 2 Leads + 1 Ground 2 Leads + 1 Ground 2 Leads + 1 Ground
Output Capacity
415 VAC
CAPACITY 17,000 34,100 51,1000
KW 5.0 10.0 15.0
380 VAC
CAPACITY 15,600 31,200 46,800
KW 4.6 9.2 13.7
Circuit Number 1 1 1
Nominal Circuit Load - Amps 12.1 24.1 36.2
Heater Circuit Maximum Fuse Size 20 35 45
Minimum Circuit Ampacity 15.9 27.9 40.0
Maximum wire Size
(60° C) CU
0 - 50 Ft. 12 10 8
51 - 100 Ft. 10 8 6
