5285473-UIM-E-1217
8 Johnson Controls Unitary Products
Table 6: Physical Data
MODELS: PCG6B36 PCG6B42 PCG6B48 PCG6B60
NOMINAL TONNAGE: 3.0 3.5 4.0 5.0
AHRI Cooling Performance
Gross Capacity @ AHRI A point (MBH) 36.5 43.3 49.1 60.0
AHRI net capacity (MBH) 36.0 42.5 45.5 58.0
EER 12.5 12.5 12.0 12.0
SEER 16.0 16.0 16.0 16.0
Nominal CFM 1200 1400 1600 2000
System power (KW) 3.0 3.4 3.6 4.6
Refrigerant type R410A R410A R410A R410A
Refrigerant charge (lb-oz) 11-8 11-4 13-8 14-0
AHRI Gas Heat Performance
Heating model 65 100 65 100 65 100 125 65 100 125
Heat input - High Fire (KBtu) 65 100 65 100 65 100 125 65 100 125
Heat output - High Fire (KBtu) 52 81 52 81 52 81 101 52 81 101
Heat input - Low Fire (KBtu) 43 65 43 65 43 65 82 43 65 82
Heat output - Low Fire (KBtu) 34 53 34 53 34 53 66 34 53 66
AFUE% 81.0 81.0 81.0 81.0 81.0 81.0 81.0 81.0 81.0 81.0
No. burners 2 3 2 3 2 3 4 2 3 4
No. stages 2 2 2 2 2 2 2 2 2 2
Temperature Rise Range - High Fire (°F) 40-70 40-70 40-70 40-70
Temperature Rise Range - Low Fire (°F) 25-55 25-55 25-55 25-55
Max. Static Pressure w.c. 0.5 0.5 0.5 0.5
Max. Outlet Air Temp. (°F) 180 180 180 180
Gas piping connection (in.) 1/2 1/2 1/2 1/2
Dimensions (inches)
Length 51-1/4 51-1/4 51-1/4 51-1/4
Width 45-3/4 45-3/4 45-3/4 45-3/4
Height 49 49 53 55
Compressor
Type Scroll Scroll Scroll Scroll
Stages 2 2 2 2
Outdoor Coil Data
Face area (Sq. Ft.) 19.5 19.5 23.8 25.9
Rows 2 2 2 2
Fins per inch 22 22 22 22
Tube diameter 3/8 3/8 3/8 3/8
Circuitry Type Interlaced Interlaced Interlaced Interlaced
Indoor Coil Data
Face area (Sq. Ft.) 6.3 6.3 6.3 6.3
Rows 3 3 3 4
Fins per inch 16 16 16 16
Tube diameter 3/8 3/8 3/8 3/8
Circuitry Type Interlaced Interlaced Interlaced Interlaced
Refrigerant control TXV TXV TXV TXV
Outdoor Fan Data
Fan diameter (Inch) 26 26 26 26
Type Prop Prop Prop Prop
Drive type Direct Direct Direct Direct
No. speeds 1 1 1 1
Motor HP each 1/3 1/3 1/3 1/3
RPM 850 850 850 850
Nominal total CFM 3200 3200 3200 3200
Continued on next page.
