246645-YTG-C-0708
42 Johnson Controls Unitary Products
FIGURE 15 - SLAB ECONOMIZER END RETURN W/POWER EXHAUST
2EE04705X24
Slab Economizer
1EH0409
Barometric Relief Hood
1EH0409
Barometric Relief Damper
1EH0409
Fresh Air Hood
2PE047032XX
Power Exhaust
Field Installed
Duct Work
