5167821-YTG-J-0518
16 Johnson Controls Ducted Systems
Capacity Performance
ZT037-061 Cooling Capacities
ZT037 High Speed Compressor (3.0 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
750
77 49.3 1.9 25.0 20.9 16.7 - - - 45.5 2.2 22.1 19.0 15.9 - - -
72 43.4 1.9 28.1 24.1 20.2 16.2 - - 40.8 2.1 26.7 23.0 19.3 15.6 - -
67 37.4 1.9 31.2 27.4 23.6 19.5 15.9 - 36.1 2.1 31.2 27.0 22.7 18.8 15.0 -
62 35.5 1.9 35.4 31.2 27.1 22.6 19.5 15.7 34.0 2.1 33.8 30.0 26.1 21.8 18.1 14.1
900
77 49.8 1.9 26.8 21.8 16.8 - - - 46.2 2.2 24.7 20.3 15.9 - - -
72 44.7 1.9 30.6 25.9 21.3 16.6 - - 42.1 2.1 29.2 24.8 20.3 15.8 - -
67 39.6 1.9 34.3 30.0 25.7 20.9 16.4 - 38.0 2.1 33.8 29.3 24.7 20.0 15.4 -
62 37.5 1.9 37.4 33.8 30.2 25.0 20.9 16.2 35.8 2.1 35.7 32.4 29.1 24.0 19.5 14.8
57 35.4 1.9 35.4 35.4 34.7 30.0 25.3 20.6 33.6 2.1 33.6 33.6 33.5 28.6 23.7 18.7
1050
77 50.4 2.0 28.6 22.7 16.8 - - - 47.0 2.2 27.3 21.6 15.9 - - -
72 46.0 1.9 33.0 27.7 22.3 17.0 - - 43.5 2.2 31.8 26.5 21.3 16.0 - -
67 41.7 1.9 37.4 32.7 27.9 22.3 17.0 - 40.0 2.1 36.4 31.5 26.7 21.2 15.8 -
62 39.5 1.9 39.4 36.4 33.4 27.4 22.2 16.7 37.7 2.1 37.5 34.8 32.1 26.3 21.0 15.4
57 37.2 1.9 37.2 37.2 36.9 33.2 27.5 21.8 35.3 2.1 35.3 35.3 35.3 31.8 26.1 20.4
1200
77 50.9 2.0 30.4 23.6 16.8 - - - 47.7 2.2 29.9 22.9 15.9 - - -
72 47.4 1.9 35.5 29.4 23.4 17.4 - - 44.8 2.2 34.4 28.3 22.2 16.2 - -
67 43.8 1.9 40.6 35.3 30.0 23.7 17.5 - 41.9 2.2 39.0 33.8 28.6 22.4 16.2 -
62 41.4 1.9 41.3 39.0 36.6 29.8 23.6 17.1 39.5 2.1 39.4 37.2 35.0 28.6 22.4 16.1
57 39.0 1.9 39.0 39.0 39.0 36.5 29.7 23.0 37.1 2.1 37.1 37.1 37.1 35.0 28.5 22.1
1350
72 48.7 2.0 37.9 31.2 24.5 17.8 - - 46.1 2.2 37.0 30.1 23.2 16.3 - -
67 46.0 2.0 43.7 37.9 32.1 25.0 18.0 - 43.8 2.2 41.6 36.1 30.6 23.6 16.6 -
62 43.4 1.9 43.3 41.5 39.8 32.2 25.0 17.6 41.3 2.1 41.2 39.6 38.0 30.8 23.8 16.7
57 40.8 1.9 40.8 40.8 40.8 39.7 32.0 24.3 38.9 2.1 38.9 38.9 38.9 38.2 31.0 23.8
1500
72 50.0 2.0 40.4 33.0 25.6 18.2 - - 47.5 2.2 39.6 31.9 24.2 16.5 - -
67 48.1 2.0 46.8 40.5 34.3 26.4 18.6 - 45.7 2.2 44.1 38.4 32.6 24.8 17.0 -
62 45.3 1.9 45.3 44.1 42.9 34.7 26.4 18.1 43.2 2.2 43.1 42.0 40.9 33.1 25.2 17.3
57 42.5 1.9 42.5 42.5 42.5 42.5 34.2 25.5 40.6 2.1 40.6 40.6 40.6 40.6 33.4 25.4
95°F 105°F
750
77 41.7 2.4 19.2 17.1 15.0 - - - 39.3 2.7 18.9 16.8 14.8 - - -
72 38.3 2.3 25.2 21.8 18.4 15.0 - - 35.4 2.7 24.0 20.8 17.5 14.2 - -
67 34.8 2.3 31.2 26.5 21.8 18.0 14.2 - 31.7 2.7 29.2 24.7 20.2 16.7 13.1 -
62 32.4 2.3 32.2 28.7 25.2 21.0 16.8 12.6 30.3 2.7 30.0 26.5 22.9 19.1 15.3 11.5
900
77 42.6 2.4 22.6 18.8 15.0 - - - 39.5 2.7 22.1 18.3 14.5 - - -
72 39.6 2.4 27.9 23.6 19.3 15.0 - - 36.5 2.7 26.6 22.4 18.2 14.0 - -
67 36.5 2.3 33.3 28.5 23.6 19.0 14.5 - 33.5 2.7 31.1 26.5 21.9 17.6 13.2 -
62 34.1 2.3 34.0 31.0 28.0 23.1 18.2 13.4 31.8 2.7 31.6 28.6 25.6 21.1 16.6 12.1
57 31.8 2.3 31.8 31.8 31.8 27.2 22.0 16.9 30.2 2.7 30.2 30.2 29.4 24.7 20.0 15.3
1050
77 43.6 2.4 26.0 20.4 14.9 - - - 39.8 2.7 25.3 19.8 14.2 - - -
72 40.9 2.4 30.7 25.4 20.2 15.0 - - 37.7 2.7 29.2 24.0 18.9 13.8 - -
67 38.2 2.4 35.4 30.4 25.5 20.1 14.7 - 35.3 2.7 33.0 28.3 23.6 18.5 13.3 -
62 35.9 2.3 35.7 33.2 30.7 25.2 19.7 14.2 33.4 2.7 33.2 30.8 28.4 23.1 17.9 12.7
57 33.5 2.3 33.5 33.5 33.5 30.3 24.7 19.0 31.6 2.7 31.6 31.6 31.6 27.8 22.5 17.2
1200
77
44.6 2.4 29.4 22.1 14.9 - - - 40.1 2.7 28.6 21.2 13.9 - - -
72 42.3 2.4 33.4 27.2 21.1 14.9 - - 38.8 2.7 31.7 25.7 19.6 13.6 - -
67 40.0 2.4 37.4 32.3 27.3 21.1 15.0 - 37.0 2.7 34.9 30.1 25.4 19.4 13.4 -
62 37.6 2.4 37.4 35.4 33.5 27.3 21.1 15.0 35.0 2.7 34.8 33.0 31.1 25.2 19.2 13.3
57 35.2 2.3 35.2 35.2 35.2 33.5 27.3 21.1 32.9 2.7 32.9 32.9 32.9 31.0 25.1 19.2
1350
72 43.6 2.4 36.1 29.0 22.0 14.9 - - 40.0 2.7 34.3 27.3 20.3 13.3 - -
67 41.7 2.4 39.5 34.3 29.1 22.1 15.2 - 38.8 2.7 36.8 31.9 27.1 20.3 13.5 -
62 39.3 2.4 39.2 37.7 36.2 29.4 22.6 15.8 36.6 2.7 36.4 35.1 33.9 27.2 20.5 13.9
57 37.0 2.3 37.0 37.0 37.0 36.6 30.0 23.3 34.3 2.7 34.3 34.3 34.3 34.1 27.6 21.1
1500
72 44.9 2.4 38.8 30.8 22.9 14.9 - - 41.1 2.7 36.9 29.0 21.0 13.1 - -
67 43.4 2.4 41.5 36.2 30.9 23.2 15.4 - 40.6 2.8 38.7 33.8 28.8 21.2 13.5 -
62 41.0 2.4 40.9 39.9 39.0 31.5 24.0 16.6 38.1 2.7 38.0 37.3 36.6 29.2 21.9 14.5
57 38.7 2.3 38.7 38.7 38.7 38.7 32.6 25.4 35.7 2.7 35.7 35.7 35.7 35.7 30.2 23.1
