York RAC13L30B23S User Manual

5752574-UTG-C-1020
Johnson Controls Ducted Systems 9
– = Not applicable.
MP Modular Air Handlers use Coil Only Ratings.
RAC13L60B23S ME20DN21 24.5 CF/CM64D 1675 56.50 42.00 13.50 11.50
RAC13L60B23S RGF29040AE10MP11 21.0 CF/CM60C 1650 56.00 41.00 13.50 11.50
RAC13L60B23S RGF29040AE10MP11 24.5 CF/CM60D 1550 56.00 40.00 13.50 11.25
RAC13L60B23S RGF29040AE10MP11 24.5 CF/CM64D 1575 56.50 41.00 13.50 11.25
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ANSI/AHRI Standard 210/240.
Cooling MBH based on 80°F entering air temperature, 50% RH (Relative Humidity), and rated airflow.
EER (Energy Efficiency Ratio) is the total cooling output in BTUs at 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTUs during a normal annual usage period for cooling divided by the total electric power input in
watt-hours during the same period.
1. CM coils available with a factory installed horizontal drain pan. Refer to the Price pages for specific model number.
COOLING CAPACITY - With Air Handler Coils (Continued)
UNIT
MODEL
AIR HANDLER
COIL
MODEL
1
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.
COOLING CAPACITY - Upflow, Downflow, and Horizontal Furnaces and Coils (Coil Only Ratings)
UNIT MODEL
COIL
CFM RANGE
(MINIMUM–
MAXIMUM)
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER
1
EER
TOTAL SENS.
RAC13L18B23S CF/CM/CU18A 14.5 450–750 600 17.2 13.0 13.00 11.50
RAC13L18B23S CF/CM/CU18B 17.5 450–750 600 17.2 13.8 13.00 11.50
RAC13L18B23S CF/CM/CU24A 14.5 450–750 600 17.4 13.9 13.00 11.50
RAC13L18B23S CF/CM/CU24B 17.5 450–750 600 17.4 13.9 13.00 11.50
RAC13L18B23S CF/CM/CU30A 14.5 450–750 600 17.6 14.1 13.00 11.50
RAC13L18B23S CF/CM/CU30B 17.5 450–750 600 17.6 14.1 13.00 11.50
RAC13L18B23S CF/CM/CU36B 17.5 450–750 600 17.6 14.0 13.25 11.75
RAC13L18B23S CF/CM/CU36C 21.0 450–750 600 17.6 14.0 13.25 11.75
RAC13L18B23S CF/CM24C 21.0 450–750 600 17.4 13.9 13.00 11.50
RAC13L18B23S CF/CM30C 21.0 450–750 600 17.6 14.1 13.00 11.50
RAC13L18B23S CF/CM36A 14.5 450–750 600 17.6 14.0 13.25 11.75
RAC13L18B23S CF/CM36D 24.5 450–750 600 17.6 14.0 13.25 11.75
RAC13L24B24S CF/CM/CU24A 14.5 600–1000 800 23.6 16.8 13.00 11.50
RAC13L24B24S CF/CM/CU24B 17.5 600–1000 800 23.6 18.9 13.00 11.50
RAC13L24B24S CF/CM/CU30A 14.5 600–1000 800 23.6 19.3 13.00 11.50
RAC13L24B24S CF/CM/CU30B 17.5 600–1000 800 23.6 19.3 13.00 11.50
RAC13L24B24S CF/CM/CU36B 17.5 600–1000 800 23.8 19.2 13.00 11.50
RAC13L24B24S CF/CM/CU36C 21.0 600–1000 800 23.8 19.2 13.00 11.50
RAC13L24B24S CF/CM/CU42C 21.0 600 - 1000 800 24.0 19.3 13.00 11.50
RAC13L24B24S CF/CM24C 21.0 600–1000 800 23.6 18.9 13.00 11.50
RAC13L24B24S CF/CM30C 21.0 600–1000 800 23.6 19.3 13.00 11.50
RAC13L24B24S CF/CM36A 14.5 600–1000 800 23.8 19.2 13.00 11.50
RAC13L24B24S CF/CM36D 24.5 600–1000 800 23.8 19.2 13.00 11.50
RAC13L24B24S CF/CM42D 24.5 600–1000 800 24.0 19.3 13.00 11.50
RAC13L24B24S CF42B 17.5 600–1000 800 24.0 19.3 13.00 11.50
RAC13L30B23S CF/CM/CU30B 17.5 800–1200 1000 28.6 21.4 13.00 11.00
RAC13L30B23S CF/CM/CU36B 17.5 800–1200 1000 29.0 23.0 13.00 11.25
RAC13L30B23S CF/CM/CU36C 21.0 800–1200 1000 29.0 23.0 13.00 11.25
RAC13L30B23S CF/CM/CU42C 21.0 800–1200 1000 29.0 22.8 13.00 11.25
RAC13L30B23S CF/CM30C 21.0 800–1200 1000 28.8 22.8 13.00 11.00
RAC13L30B23S CF/CM36A 14.5 800–1200 900 28.6 21.8 13.00 11.00
RAC13L30B23S CF/CM36D 24.5 800–1200 1000 29.0 23.0 13.00 11.25
RAC13L30B23S CF/CM42D 24.5 800–1200 1000 29.0 22.8 13.00 11.25
RAC13L36B24S CF/CM/CU36B 17.5 1000–1400 1200 35.4 23.6 13.00 11.00
RAC13L36B24S CF/CM/CU36B 17.5 1000–1400 1200 35.4 23.6 13.00 11.00
