Air intake temperature to indoor coil
Nominal 400 V
Notes: WB = Wet bulb. DB = Dry bulb. (1) At below -20°C, only the emergency electric heater (optional) remains operative. (2) This equipment can operate, for a short interval of time, at a temperature below
10°C so as to raise the air temperature of the conditioned space to 10°C.
Operating cycle
Maximum °C
Minimum °C
Maximum °CMinimum °C
Voltage limits
Operating cycle
Air intake temperature to outdoor coil DB
Limits of use
342
Minimum
436
Maximum
Cool
19
46
Cool
24
Heat
15
Cool WB
10
(2)
Heat DB
23
Cool WB Heat DB
32
Heat
-20
(1)
Important: Automatic switch dimensioning and power supply line sections are orientative and should be corrected in accordance with conditions at job site, length between units and legislation in force.
Notes: 1.- K curve (DIN, VDE 0660-104). 2.- Based on copper conductors.
Electrical characteristics
Outdoor units
Power supply V.ph.Hz.
Intensity A
Compressor
Fan
Compressor
Fan
Model
Start
Nominal
Start
Nominal m m
2
A
Power
supply cable
section (2)
Automatic
switch
(K curve)(1)
400.3.50 400.3.50 99 14,6 14 2,8 4 20
400.3.50 400.3.50 123 17,9 14 2,8 4 25
400.3.50 400.3.50 134 18,1 31 5,6 6 32
400.3.50 400.3.50 167 23,4 31 5,6 10 40
400.3.50 400.3.50 2 x 99 2 x 14,6 2 x 17 2 x 4,3 10 50
400.3.50 400.3.50 2 x 134 2 x 16,9 2 x 17 2 x 4,3 16 63
400.3.50 400.3.50 2 x 167 2 x 18,8 2 x 38 2 x 7,4 25 80
400.3.50 400.3.50 2 x 189 2 x 25,8 2 x 38 2 x 7,4 35 100
SCOH-120K
SCOH-070K
SCOC-180K /
SCOH-180K
SCOH-240K
SCOH-300K
SCOC-076K /
SCOH-076K
SCOC-090K /
SCOH-090K
SCOC-150K /
SCOH-150K
