Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
Continued on next page.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. TCHD18S41S3
INDOOR COIL MODEL NO. FC/MC/PC24
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 450 600 750
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65
T.C. 17.3 18.2 18.6 19.7 21.5 18.9 19.0 19.2 20.6 22.5 20.4 19.7 19.8 21.5 23.4
S.C. 16.6 14.5 12.6 12.2 9.9 18.0 16.9 14.3 14.2 10.7 19.4 19.3 15.9 16.2 11.6
KW 1.07 1.08 1.09 1.08 1.07 1.07 1.07 1.09 1.07 1.07 1.07 1.07 1.08 1.07 1.08
75
T.C. 16.2 17.3 17.8 18.9 20.7 17.8 18.2 18.4 19.7 21.5 19.4 19.1 19.0 20.5 22.3
S.C. 15.7 13.9 12.2 11.8 9.6 17.2 16.4 13.9 13.7 10.5 18.7 18.8 15.6 15.6 11.4
KW 1.28 1.28 1.28 1.27 1.25 1.27 1.27 1.27 1.26 1.25 1.26 1.26 1.27 1.26 1.26
85
T.C. 15.1 16.5 16.9 18.1 20.0 16.7 17.5 17.6 18.9 20.5 18.3 18.5 18.2 19.6 21.1
S.C. 14.8 13.3 11.8 11.4 9.3 16.4 15.8 13.5 13.1 10.2 18.0 18.4 15.3 14.9 11.2
KW 1.48 1.48 1.47 1.46 1.44 1.46 1.46 1.46 1.45 1.43 1.44 1.44 1.46 1.44 1.43
95
T.C. 14.0 15.7 16.1 17.3 19.2 15.6 16.8 16.8 18.0 19.6 17.3 18.0 17.4 18.7 19.9
S.C. 14.0 12.7 11.3 11.0 8.9 15.7 15.3 13.1 12.6 10.0 17.4 17.9 14.9 14.2 11.0
KW 1.68 1.68 1.66 1.64 1.62 1.65 1.66 1.65 1.64 1.61 1.63 1.63 1.64 1.63 1.61
105
T.C. 13.4 14.5 14.9 16.0 18.1 14.8 15.6 15.6 16.8 18.5 16.3 16.7 16.2 17.6 18.9
S.C. 13.3 12.2 10.7 10.4 8.5 14.8 14.5 12.4 12.0 9.5 16.3 16.7 14.1 13.7 10.5
KW 2.16 2.12 2.11 2.12 1.93 2.08 2.06 2.07 2.04 1.92 1.99 1.99 2.02 1.95 1.91
115
T.C. 12.7 13.5 13.7 14.7 16.9 14.0 14.5 14.4 15.6 17.4 15.3 15.6 15.1 16.5 17.9
S.C. 12.6 11.6 10.0 9.8 8.0 14.0 13.6 11.6 11.5 9.0 15.3 15.6 13.2 13.2 10.0
KW 2.63 2.54 2.55 2.58 2.23 2.48 2.44 2.47 2.42 2.21 2.34 2.34 2.40 2.27 2.20
125
T.C. 12.1 12.4 12.6 13.4 15.8 13.2 13.4 13.2 14.4 16.3 14.3 14.4 13.9 15.5 16.8
S.C. 12.0 11.1 9.4 9.2 7.6 13.1 12.8 10.9 10.9 8.5 14.3 14.5 12.4 12.7 9.5
KW 3.10 2.97 3.00 3.04 2.53 2.89 2.83 2.88 2.81 2.51 2.69 2.68 2.77 2.58 2.49
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handlers Coils T.C. S.C. KW
– FC/MC/PC30 1.00 1.00 1.00
– FC/MC/PC32 1.01 1.00 1.00
– FC/MC/PC35 1.01 1.00 1.00
– FC/MC/PC36 1.01 1.00 1.00
– FC/MC/PC37 1.02 1.01 1.00
– HC36 1.01 1.00 1.00
– HD24 1.04 1.02 1.01
– UC24 1.01 1.00 1.00
– UC30 1.01 1.00 1.00
AHX18 – 1.01 1.04 0.95
AHX24 – 1.02 1.03 0.95
AHX30 – 1.03 1.06 0.95
AV*24 – 1.01 1.04 0.96
AV*36 – 1.06 1.10 0.97
F6FP018 – 0.99 1.00 0.97
F6FP024 – 1.03 1.04 0.98
F6FP030 – 1.03 1.05 0.98
MV12B FC/MC18B 1.00 0.98 0.93
MV12B FC/MC24B 1.02 1.02 0.93
MV12B FC/MC30B 1.02 1.02 0.93
