Opti
Speed compressor dr
ive details
Sy
stem ar
chit
ecture
Figure 3: OptiSpeed system ar
chitecture (Model VSD 351 without harmonic filter shown,
similar to 270, 292, 424 models)
Callout
Description
Callout
Description
1
Cooling coil
4
Control tr
ansformer
2
Cooling fans
5
Input break
er
3
Inductor
Liquid-Cooled OptiSpeed Compressor Speed Drive
22
21
23
