SECTION 5 – TECHNICAL DATA
FORM 150.67-NM1
ISSUE DATE: 4/28/2017
55
SYSTEM #1 COMPRESSOR & FAN SYSTEM #2 COMPRESSOR & FAN
COMPR. #1 COMPR. #2 FANS COMPR. #1 COMPR. #2 FANS
RLA LRA RLA LRA QTY FLA RLA RLA LRA RLA LRA QTY FLA RLA
42.2 250 42.2 250 2 2.6 5.0 — — — — — — —
39.0 250 39.0 250 2 2.6 5.0 — — — — — — —
22.5 155 22.5 155 2 1.6 3.0 — — — — — — —
18.6 114 18.6 114 2 1.3 2.5 — — — — — — —
14.9 100 14.9 100 2 1.0 2.0 — — — — — — —
45.4 250 45.4 250 2 2.6 5.0 — — — — — — —
42.0 250 42.0 250 2 2.6 5.0 — — — — — — —
24.2 155 24.2 155 2 1.6 3.0 — — — — — — —
20.0 125 20.0 125 2 1.3 2.5 — — — — — — —
16.0 100 16.0 100 2 1.0 2.0 — — — — — — —
51.3 300 55.8 425 2 7.6 44.0 — — — — — — —
51.3 300 55.8 425 2 7.4 19.1 — — — — — — —
26.9 139 36.0 239 2 4.5 23.1 — — — — — — —
23.1 150 26.9 187 2 4.0 19.0 — — — — — — —
19.9 109 23.7 148 2 2.9 15.3 — — — — — — —
59.9 425 59.9 425 2 7.6 30.9 — — — — — — —
55.5 425 55.5 425 2 7.4 37.0 — — — — — — —
32.0 239 32.0 239 2 4.5 22.3 — — — — — — —
26.4 187 26.4 187 2 3.4 17.2 — — — — — — —
21.1 148 21.1 148 2 2.9 14.6 — — — — — —
—
45.4 250 45.4 250 2 7.6 30.9 45.4 250 45.4 250 2 7.6
30.9
42.0 250 42.0 250 2 7.4 37.0 42.0 250 42.0 250 2 7.4 37.0
24.2 155 24.2 155 2 4.5 22.3 24.2 155 24.2 155 2 4.5 22.3
20.0 125 20.0 125 2 3.4 17.2 20.0 125 20.0 125 2 3.4 17.2
16.0 100 16.0 100 2 2.9 14.6 16.0 100 16.0 100 2 2.9 14.6
47.0 250 47.0 250 2 7.6 30.9 45.4 250 45.4 250 2 7.6 30.9
43.5 250 43.5 250 2 7.4 37.0 42.0 250 42.0 250 2 7.4 37.0
25.1 155 25.1 155 2 4.5 22.3 24.2 155 24.2 155 2 4.5 22.3
20.7 125 20.7 125 2 3.4 17.2 20.0 125 20.0 125 2 3.4 17.2
16.6 100 16.6 100 2 2.9 14.6 16.0 100 16.0 100 2 2.9 14.6
51.3 300 51.3 300 2 7.6 44.0 51.3 300 51.3 300 2 7.6 44.0
51.3 300 51.3 300 2 7.4 19.1 51.3 300 51.3 300 2 7.4 19.1
26.9 139 26.9 139 2 4.5 23.1 26.9 139 26.9 139 2 4.5 23.1
23.1 150 23.1 150 2 4.0 19.0 23.1 150 23.1 150 2 4.0 19.0
19.9 109 19.9 109 2 2.9 15.3 19.9 109 19.9 109 2 2.9 15.3
Single-Point Field Supplied Power Wiring (See Figure 12)
(One Field Provided Power Supply to the chiller. Field connections to Factory Provided Power Terminal Block (standard), Non-Fused
Disconnect Switch (optional) or Circuit Breaker (optional)).
ELECTRICAL DATA (ENGLISH) (CONT’D)
YCAL0019_ – YCAL0066_
