57
JOHNSON CONTROLS
SECTION 5 – TECHNICAL DATA
FORM 150.67-NM1
ISSUE DATE: 4/28/2017
55
SYSTEM #1 COMPRESSOR & FAN SYSTEM #2 COMPRESSOR & FAN
COMPR. #1 COMPR. #2 FANS COMPR. #1 COMPR. #2 FANS
RLA LRA RLA LRA QTY FLA RLA RLA LRA RLA LRA QTY FLA RLA
55.8 425 55.8 425 2 7.6 44.0 55.8 425 55.8 425 2 7.6 44.0
55.8 425 55.8 425 2 7.4 19.1 55.8 425 55.8 425 2 7.4 19.1
36.0 239 36.0 239 2 4.5 23.1 36.0 239 36.0 239 2 4.5 23.1
26.9 187 26.9 187 2 4.0 19.0 26.9 187 26.9 187 2 4.0 19.0
23.7 148 23.7 148 2 2.9 15.3 23.7 148 23.7 148 2 2.9 15.3
76.9 505 76.9 505 2 7.6 30.9 59.9 425 59.9 425 2 7.6 30.9
71.2 505 71.2 505 2 7.4 37.0 55.5 425 55.5 425 2 7.4 37.0
41.1 280 41.1 280 2 4.5 22.3 32.0 239 32.0 239 2 4.5 22.3
33.9 225 33.9 225 2 3.4 17.2 26.4 187 26.4 187 2 3.4 17.2
27.1 180 27.1 180 2 2.9 14.6 21.1 148 21.1 148 2 2.9 14.6
Single-Point Field Supplied Power Wiring (See Figure 12)
(One Field Provided Power Supply to the chiller. Field connections to Factory Provided Power Terminal Block (standard), Non-Fused
Disconnect Switch (optional) or Circuit Breaker (optional)).
ELECTRICAL DATA (ENGLISH) (CONT’D)
YCAL0019_ – YCAL0066_
