York YCAQ10 User Manual

6 YORK INTERNATIONAL
PHYSICAL DATA
MODEL YCA Q10, R11 M12, N13 K14, L15 I16, J17 G18, H19
NO. OF REFRIG. CIRCUITS 12222
COMPRESSOR
60 HZ
SYS. 1 JS83F-S JS43F-M JS63F-P JS63-F-P JS83F-S
SYS 2 – JS63F-P JS63F-P JS83F-S JS83F-S
MODEL
50 HZ
SYS. 1 JS84F-T JS44F-P JS64F-P JS64F-S JS84F-T
SYS. 2 – JS64F-S JS64F-S JS84F-T JS84F-T
IF SYS.1
LEAD 100,75,50,25 100,60,40,20 100,67,50,17 100,71,43,14 100,75,50,25
UNIT
STD.
IF SYS. 2 – 100,80,60,20 100,67,50,17 100,71,57,29 100,75,50,25
CAPACITY LEAD
CONTROL IF SYS.1 – 100,80,60,40,20 100,83,67, 100,86,71,57, 100,88,75,62,
%
OPT
LEAD 50,33,17 43,29,14 50,38,25,12
IF SYS. 2 – 100,80,60,40,20 100,83,67, 100,86,71,57, 100,88,75,62,
LEAD 50,33,17 43,29,14 50,38,25,12
OIL SYS.1 33333
CHARGE (GALS) SYS. 2 –3333
CONDENSER – DWP 450 PSIG
NO. OF FANS (30" Dia. Direct Drive) 47888
CFM (EACH)
60 HZ. 11,000 11,000 11,000 11,000 11,000
50 HZ. 11,000 11,000 11,000 11,000 11,000
COOLER – DUAL CIRCUITED
DWP – 235 PSIG REF. SIDE,
150 PSIG WATER SIDE
DIA. x LENGTH 14" x 7' 14" x 8' 14" x 8' 16" x 8' 18" x 9'
WATER VOLUME (GALS) 31 36 33 39 49
GPM
MIN 120 120 120 150 200
MAX. 550 580 580 640 700
SHIPPING
ALUM. FINS 6,760 10,080 11,150 12,115 13,840
WEIGHTS
COPPER FINS 8,435 11,980 12,650 15,115 17,340
(LBS.)
OPERATING
ALUM FINS 7,000 10,400 11,540 12,505 14,500
COPPER FINS 8,675 12,300 13,040 15,505 18,000
REFRIG.
SYS.1 135 87 116 116 133
CHARGE (LBS.) R-22
SYS. 2 – 116 116 133 133

York YCAQ10 Specifications

General

Brand	York
Model	YCAQ10
Category	Chiller
Language	English
