— = Not applicable.
MP Modular Air Handlers use Coil Only Ratings.
YCD60B21S AE60CX21 21.0 – 1625 56.0 40.0 13.25 11.25
YCD60B21S AE60DX21 24.5 – 1775 57.0 41.5 13.25 11.25
YCD60B21S AP60CX21 21.0 – 1525 54.5 38.0 13.00 10.75
YCD60B21S AP60DX21 24.5 – 1550 55.0 38.5 13.00 10.75
YCD60B21S AVC60CX21 21.0 – 1750 56.0 41.0 13.00 11.25
YCD60B21S AVC60DX21 24.5 – 1650 56.5 40.5 13.50 11.25
YCD60B21S ME16CN21 21.0 CF/CM60C 1625 56.0 40.0 13.50 11.25
YCD60B21S ME20DN21 24.5 CF/CM60D 1650 56.0 40.0 13.50 11.25
YCD60B21S ME20DN21 24.5 CF/CM64D 1625 56.5 40.5 13.50 11.50
YCD60B21S MVC16CN21 21.0 CF/CM60C 1650 56.5 40.5 14.25 12.00
YCD60B21S MVC20DN21 24.5 CF/CM60D 1700 56.0 40.0 13.50 11.25
YCD60B21S MVC20DN21 24.5 CF/CM64D 1700 56.5 40.0 13.50 11.25
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ANSI/AHRI Standard 210/240.
Cooling MBH based on 80°F entering air temperature, 50% RH (Relative Humidity), and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTUs at 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTUs during a normal annual usage period for cooling divided by the total
electric power input in watt-hours during the same period.
1. CM coils available with a factory installed horizontal drain pan. See price pages for specific model number.
COOLING CAPACITY - With Air Handler Coils (Continued)
UNIT
MODEL
AIR HANDLER
COIL
MODEL
1
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.
COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils (Coil Only Ratings)
UNIT MODEL
COIL
CFM RANGE
(MIN.-MAX.)
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER
1
EER
TOTAL SENS.
YCD18B21(H,S) CF/CM/CU18A 14.5 450 - 750 600 17.5 13.3 13.00 11.00
YCD18B21(H,S) CF/CM/CU18B 17.5 450 - 750 600 17.5 13.3 13.00 11.00
YCD18B21(H,S) CF/CM/CU24A 14.5 450 - 750 600 18.0 13.8 13.00 11.00
YCD18B21(H,S) CF/CM/CU24B 17.5 450 - 750 600 18.0 13.8 13.00 11.00
YCD18B21(H,S) CF/CM/CU24C 21.0 450 - 750 600 18.0 13.8 13.00 11.00
YCD18B21(H,S) CF/CM/CU30A 14.5 450 - 750 600 18.0 13.9 13.00 11.25
YCD18B21(H,S) CF/CM/CU30B 17.5 450 - 750 600 18.0 13.9 13.00 11.25
YCD18B21(H,S) CF/CM/CU30C 21.0 450 - 750 600 18.0 13.9 13.00 11.25
YCD18B21(H,S) CF/CM/CU30D 24.5 450 - 750 600 18.0 13.9 13.00 11.25
YCD18B21(H,S) CF/CM/CU36B 17.5 450 - 750 600 18.0 13.6 13.00 11.25
YCD18B21(H,S) CF/CM/CU36C 21.0 450 - 750 600 18.0 13.6 13.00 11.25
YCD18B21(H,S) CF/CM/CU36D 24.5 450 - 750 600 18.0 13.6 13.00 11.25
YCD18B21(H,S) CF/CM36A 14.5 450 - 750 600 18.0 13.6 13.00 11.25
YCD24B21(H,S) CF/CM/CU24A 14.5 600 - 1000 800 23.6 17.4 13.00 11.00
YCD24B21(H,S) CF/CM/CU24B 17.5 600 - 1000 800 23.6 17.4 13.00 11.00
YCD24B21(H,S) CF/CM/CU24C 21.0 600 - 1000 800 23.6 17.4 13.00 11.00
YCD24B21(H,S) CF/CM/CU30A 14.5 600 - 1000 800 24.0 17.8 13.00 11.00
YCD24B21(H,S) CF/CM/CU30B 17.5 600 - 1000 800 24.0 17.8 13.00 11.00
YCD24B21(H,S) CF/CM/CU30C 21.0 600 - 1000 800 24.0 17.8 13.00 11.00
YCD24B21(H,S) CF/CM/CU30D 24.5 600 - 1000 800 24.0 17.8 13.00 11.00
YCD24B21(H,S) CF/CM/CU36B 17.5 600 - 1000 800 24.0 17.4 13.00 11.00
YCD24B21(H,S) CF/CM/CU36C 21.0 600 - 1000 800 24.0 17.4 13.00 11.00
YCD24B21(H,S) CF/CM/CU36D 24.5 600 - 1000 800 24.0 17.4 13.00 11.00
YCD24B21(H,S) CF/CM/CU42C 21.0 600 - 1000 800 24.0 17.6 13.00 11.25
YCD24B21(H,S) CF/CM/CU42D 24.5 600 - 1000 800 24.0 17.6 13.00 11.25
YCD24B21(H,S) CF/CM36A 14.5 600 - 1000 800 24.0 17.4 13.00 11.00
