York YCJD30 User Manual

553202-YTG-A-1209
Johnson Controls Unitary Products 9
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. YCJD30S4(3,4)S3
INDOOR COIL MODEL NO. FC/MC/PC35
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 800 1000 1200
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65
T.C. 28.4 31.4 30.8 33.1 34.4 29.8 31.8 31.4 33.4 34.5 31.2 32.3 32.1 33.7 34.7
S.C. 28.8 25.8 21.7 21.2 16.0 30.4 28.2 23.6 22.6 17.1 31.9 30.7 25.4 24.0 18.1
KW 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.7
75
T.C. 26.4 28.8 28.2 30.9 32.6 27.9 29.7 28.9 31.4 32.8 29.5 30.5 29.6 31.8 32.9
S.C. 26.9 24.7 20.5 20.3 15.4 28.5 27.1 22.6 22.0 16.4 30.2 29.5 24.6 23.7 17.5
KW 1.8 1.8 1.8 1.9 1.9 1.8 1.8 1.8 1.9 1.9 1.9 1.9 1.9 1.9 1.9
85
T.C. 24.4 26.3 25.6 28.8 30.9 26.0 27.5 26.4 29.3 31.0 27.7 28.7 27.1 29.8 31.2
S.C. 24.9 23.6 19.4 19.4 14.7 26.6 26.0 21.6 21.4 15.8 28.4 28.4 23.9 23.4 16.8
KW 2.0 2.0 2.0 2.0 2.1 2.0 2.0 2.0 2.0 2.1 2.0 2.0 2.0 2.1 2.1
95
T.C. 22.4 23.8 23.0 26.7 29.1 24.2 25.3 23.8 29.0 29.3 26.0 26.9 24.7 27.9 29.4
S.C. 22.9 22.5 18.2 18.5 14.1 24.8 24.9 20.7 21.2 15.1 26.7 27.3 23.1 23.1 16.2
KW 2.1 2.1 2.1 2.2 2.3 2.2 2.2 2.2 2.2 2.3 2.2 2.2 2.2 2.2 2.3
105
T.C. 20.5 21.8 20.4 23.7 26.3 22.0 23.1 21.3 24.3 26.4 23.6 24.5 22.1 24.8 26.4
S.C. 21.0 20.7 17.1 17.4 13.2 22.6 22.7 19.1 19.7 14.3 24.3 24.7 21.0 22.0 15.4
KW 2.3 2.3 2.3 2.4 2.4 2.4 2.4 2.3 2.4 2.5 2.4 2.4 2.3 2.4 2.5
115
T.C. 18.6 19.8 17.9 20.9 23.5 19.9 21.0 18.8 21.4 23.5 21.2 22.2 19.6 21.8 23.6
S.C. 19.1 18.9 15.9 16.4 12.3 20.5 20.5 17.5 18.6 13.5 22.0 22.2 19.1 20.9 14.7
KW 2.5 2.5 2.4 2.5 2.6 2.5 2.5 2.5 2.5 2.6 2.6 2.6 2.5 2.6 2.6
125
T.C. 16.8 17.9 15.4 18.1 20.7 17.8 18.9 16.2 18.5 20.7 18.9 19.9 17.1 18.8 20.7
S.C. 17.3 17.2 14.8 15.3 11.4 18.4 18.4 16.0 17.6 12.6 19.6 19.6 17.1 19.8 13.9
KW 2.7 2.7 2.6 2.7 2.8 2.7 2.7 2.6 2.7 2.8 2.7 2.7 2.7 2.7 2.8
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handlers Coils T.C. S.C. KW
– FC/MC/PC35 1.00 1.00 1.00
– FC/MC/PC37 1.00 1.00 1.00
– FC/MC/PC43 1.00 1.00 1.00
– HC36 1.00 1.00 1.00
– HC42 1.00 1.00 1.00
AHP30 – 1.00 1.00 1.00
AHP36 – 1.00 1.00 1.00
AHX30 – 1.01 1.06 0.95
AHX36 – 1.03 1.06 0.95
MA12B FC/MC35B 1.00 1.00 1.00
MA12B FC/MC43B 1.00 1.00 1.00
F4FP040 – 1.00 1.00 1.00
F6FP030 – 1.01 1.03 0.97
F6FP036 – 1.01 1.02 0.93
Furnaces Coils T.C. S.C. KW
T*(8,L)X*A12 FC/MC/PC32A 1.01 1.02 1.01
T*(8,L)X*B12 FC/MC/PC35B 1.03 1.09 0.99
T*(8,L)X*C16 FC/MC/PC35C 1.03 1.09 0.95
T*(8,L)X*C20 FC/MC/PC35C 0.99 0.98 0.91
T*9X*B12 FC/MC/PC35B 1.03 1.09 0.94
T*9X*C16 FC/MC/PC35C 1.03 1.07 0.94
T*(8,L)X*A12 FC/MC/PC37A 1.03 1.09 0.99
T*(8,L)X*B12 FC/MC/PC43B 1.03 1.09 0.95
T*(8,L)X*C16 FC/MC/PC43C 0.97 0.92 0.89
T*(8,L)X*C20 FC/MC/PC43C 1.02 1.01 0.94
T*9X*B12 FC/MC/PC43B 1.03 1.09 0.99
T*9X*C16 FC/MC/PC43C 1.03 1.09 0.95
T*9X*C20 FC/MC/PC43C 0.97 0.92 0.89
