Additional R-410A Charge / Orifice Size for Various Matched Systems

Outdoor Unit YCJF24S41S1 YCJF30S41S1 YCJF36S41S1 YCJF42S41S1 YCJF48S41S1 YCJF60S41S1

Required Orifice or TXV

1TVM(902/4F1) 1TVM(903/4G1) 1TVM(903/4G1) 1TVM(903/4G1) 1TVM(905/4J1) 1TVM(906/4K1)

Factory Charge, lbs-oz 3 - 2 3 - 7 3 - 10 4 - 4 4 - 9 5 - 9

Indoor Coil

2,3,4

Additional Charge, Oz

FC/MC/PC24A3X 5 – – – – –

FC/MC/PC24B3X 5 – – – – –

FC/MC/PC30A3X 12 2 – – – –

FC/MC/PC30B3X 12 2 – – – –

FC/MC/PC32A3X 16 10 – – – –

FC/MC/PC35B3X 16 10 8 – – –

FC/MC/PC35C3X 16 10 8 – – –

FC/MC/PC36A3X 8 4 1 – – –

FC/MC/PC36B3X 8 4 1 – – –

FC/MC/PC36C3X 8 4 1 – – –

FC/MC/PC37A3X 24 19 15 – – –

FC/MC/PC43B3X 24 19 15 5 – –

FC/MC/PC43C3X 24 19 15 5 – –

FC/MC/PC48C3X 40 32 15 17 16 –

FC/MC/PC48D3X 40 32 27 17 16 –

FC/MC/PC60D3X – – – 17 16 0

FC/MC62D3X – – – 25 26 18

UC24A3X 8 – – – – –

UC24B3X 8 – – – – –

UC30A3X 8 4 – – – –

UC30B3X 8 4 – – – –

UC36A3X – – – – – –

UC36B3X – – – – – –

UC36C3X – – – – – –

UC42B3X – – – – – –

UC42C3X – – – – – –

UC48C3X – – – – – –

UC48D3X – – – – – –

UC60C3X – – 12 – – –

UC60D3X – – 12 – – –

HC18A3X – – – – – –

HC30A3X 10 – – – – –

HC36B3X 16 11 8 – – –

HC42C3X 25 19 15 6 – –

HC60D3X – – – 0 0 0

HD24*3X 16 – – – – –

HD36*3X 18 – – – – –

HD48*3X 51 42 36 24 25 –

HD60*3X – – – – 24 –

AHP18B3X – – – – – –

AHP24B3X 3 – – – – –

AHP30B3X 16 – – – –

AHP36C3X – 19 15 – – –

AHP42C3X – – – – – –

AHP/SHP60D3X – – – – 1 –

AV24B3X 3 – – – – –

AV36C3X 25 19 15 – – –

AV/SV48D3X – – 9 0 1 –

AV/SV60D3X – – – 0 1 0

For notes see Page 4.
