Zanussi ZOA35502XD User Manual

CAUTION!
Be careful when you remove the
shelf supports. The catalytic panels
are not attached to the oven walls
and can fall out when you remove
the shelf supports.
1
Pull the front of the
shelf support away
from the side wall.
Hold the rear shelf
runners and catalytic
panel in place with
the other hand.
1
2
1
2
Pull the rear end of
the shelf support
away from the side
wall and remove it.
2
Install the shelf supports in the opposite
sequence.
Catalytic cleaning
CAUTION!
Do not clean the catalytic surface
with oven sprays, abrasive cleaning
agents, soap or other cleaning
agents. This will damage the
catalytic surface.
Spots or discolouration of the
catalytic surface have no effect on
catalytic properties.
WARNING!
Keep children away when you clean
the oven at a high temperature. The
oven surface becomes very hot and
there is a risk of burns.
Before activating the catalytic
cleaning remove all the accessories
from the oven.
The walls with a catalytic coating are self-
cleaning. They absorb fat which collects on the
walls while the appliance operates.
To support the self-cleaning procedure, heat
the empty oven on a regular basis.
1. Clean the oven floor with warm water and
washing up liquid, then dry it.
2. Set the function .
3. Set the oven temperature to 250 °C and let
the oven operate for 1 hour.
4. When the appliance is cool, clean it with a
soft and moist sponge.
Oven ceiling
WARNING!
Deactivate the appliance before you
remove the heating element. Make
sure that the appliance is cold.
There is a risk of burns.
Remove the shelf supports.
You can remove the heating element to clean
the oven ceiling more easily.
1. Remove the screw which holds the heating
element. For the first time, use a
screwdriver.
2. Carefully pull the heating element down.
3. Clean the oven ceiling with a soft cloth with
warm water and a cleaning agent, and let it
dry.
Install the heating element in the opposite
sequence.
Install the shelf supports.
WARNING!
Make sure that the heating element
is correctly installed and that it does
not fall down.
www.zanussi.com 17

Zanussi ZOA35502XD Specifications

General

Grill	Yes
Oven size	-
Oven type	Electric
Cleaning type	Catalytic
Number of ovens	1
Total oven power	- W
Total oven(s) interior capacity	74 L
Door hinge	down
Noise level	- dB
Display type	LED
Product color	Black, Stainless steel
Control position	Front
Number of glass door panels	2
Timer type	Digital
AC input voltage	240 V
Energy consumption (conventional)	0.93 kWh
Energy consumption (forced convection)	0.88 kWh

Weight and Dimensions

Depth	568 mm
Width	594 mm
Height	589 mm
Weight	32800 g
Installation compartment depth	550 mm
Installation compartment width	560 mm
Installation compartment height	600 mm
